| Launch Date: | January 31, 2015 |
| Special Feature(s): | 4K Display; QFHD+ (3840x2160)
Intel Z97 Express Chipset
Desktop LGA 1150 Processors
|
| Main Chipset: | Intel Z97 Express Chipset
PCI 2.0 |
| Processor: | Socket LGA 1150
TDP up to 90W
Xeon E3 12xx V3 processors
Intel i7 4xx0 processors |
| Video / GPU: | MXM 3.0b; modular
NVDIA GeForce: GTX 980M, GTX 970M or GTX 965M
NVIDIA Quadro: K1100M, K3100M or K5100M
|
| Built-in PC Camera: | Built-in 2M FHD Webcam |
| LCD Size: | 15.6in (39.62cm) |
| LCD Specifications: | 15.6" (39.62cm) WLED backlit; eDP; IPS
FHD (1920x1080 @60Hz); 4K QFHD+ (3840x2160 @60Hz) or WQHD+ (2880x1620 @60Hz)
Supports up to 4 active internal and/or external displays;up to 3084x2160 @ 60Hz
|
| Memory: | Four 204-pin SODIMM sockets
DDR3L-1600 or 1866; 1.35V
up to 32GB |
| Total Storage: | up to 4 physical drives:
- 2x M.2 2280 PCIe 2x/4x SSD or SATA3 SSD
- 2x HDD/SSD SATA3 6Gb/s (9.5mm)
- Intel Rapid Start Technology
- Intel Smart Response Technology
- RAID 0/1/5/10 with SATA3 drives |
| Optical Drive: | External USB based
DVD-RW or Blu Ray Burner
|
| Card Reader: | 6-in-1 Push-Push Card Reader
MMC/RSMMC
SD/mini SD/SDHC/SDXC
UHS-II interface (up to 2TB) |
| Operating Systems Supported: | Microsoft Server 2012R2
Linux (Ubuntu)
Microsoft Windows 7 and 8.1 |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in array microphone
Built in two 2W speakers
Sound Blaster X-FI MB3
External 7.1CH output (headphone, mic, line-in and S/PDIF)
ANSP 3D Sound Technology (headphone output) |
| LAN/WLAN/Bluetooth: | - WLAN / Bluetooth; M.2 2230 slot
- 10/100/1000 Ethernet LAN on-board; Realtek RT8111G
|
| Security: | Kensington Lock
Fingerprint
TPM 2.0 on-board (Infineon SLB9665-TCG) |
| Internal cards / # of slots/Type: | Three M.2 card slots
-1st for WLAN Combo M.2 2230 Card with PCIe x2 and USB interface (A Key)
-2nd for SSD M.2 2280 Card with SATA / PCIe x2/x4 interface (M Key)
-3rd for SSD M.2 2280 Card with SATA / PCIe x2/x4 interface (M key)
|
| I/O Ports: | 4 x USB 3.0 (1x powered USB port, AC/DC)
1 x eSATA/USB3.0 Combo port
2 x Display Port 1.2 (up to 3840x2160 @60Hz)
1 x HDMI 2.0 output (up to 3840x2160 @60Hz)
1 x Headphone
1 x Microphone-in
1 x S/PDIF (digital)
1 x Line in
1 x RJ-45 LAN
1 x DC-in |
| Internal Keyboard: | Backlit full size keyboard with numeric pad
TouchPad with multi-gesture and scrolling
W/A/S/D Gaming key |
| AC Adapter: | 230W 100-240V 50-60Hz Auto-switching (worldwide)
DC Output 19.5V, 11.8A
Optional 330W AC Adapter |
| Battery: | 8cells Smart Li-Ion; 82WH
up to 130 minutes |
| Weight: | 3.4kg (7.48lbs) |
| Dimensions WxDxH: | 386x262x35mm / 15.4x10.48x1.4-inch
|
| Thickness: | 1.4in (35mm)
|
| Shipping / Packaging L xWx H / N.W. / G.W.: | 547x112x319mm / 21.88x4.48x12.76 inch
5.48kg / 12lbs |
