15.6" (39.62cm); FHD IPS 1920-by-1080 pixels; WLED backlit; eDP; LCD panel
World's first Intel Xeon based, 15.6" lightweight 7.5lbs (3.4kg) Mobile Server with integrated display, keyboard and built-in internal battery (UPS)! EUROCOM S5 Pro Mobile Server supports up to 20TB of storage with four SATA3 6Gb/s physical drives in RAID 0/1/5/10, up to 32GB of memory and is powered by Intel's line of XEON E3-1200 v3 series processors.
Weight/Dimensions: 3.4kg (7.48lbs); 386x262x35mm (15.4x10.48x1.4-inch)
Operating Systems: Microsoft: Server 2012R2, 2016; Windows 7; Windows 8.1; Linux/Ubuntu
Core Logic: Intel Z97 Express Chipset; PCI 2.0
Processor: 4-core/8 treads Intel XEON E3-1200 v3 series; up to E3-1281 v3; socket LGA1150
Memory: up to 32GB; DDR3-1333/1600/1866; four physical SODIMM sockets
Storage: up to 20TB of storage with four physical drives (2x M.2 + 2x 2.5"); SATA3 6Gb/s; additional storage available via eSATA drives - NVME M.2 Drives have limited support in Windows 7 -
Redundancy and Performance: RAID 0/1/5/10
Network:1GbE; RJ-45 LAN on-board; Realtek RT8111G
I/O Ports: 4x USB 3.0; eSATA; 2x DP 1.2; HDMI 2.0; Headphone; Microphone; S/PDIF out; Line-in; RJ-45 / LAN
Security: Kensington Lock; Fingerprint; TPM 2.0 on-board (Infineon SLB9665-TCG) |
