| Launch Date: | May 30, 2025 |
| Special Feature(s): | Intel Arrow Lake HX platform; Intel Core Ultra 9, 275HX 24C/24T/36M cache; NVIDIA GeForce RTX 5070Ti (12GB DDR7) |
| Main Chipset: | Intel HM870 Express Chipset |
| Processor: | Intel Core Ultra 9, 275HX 24C/24T/36M cache
|
| Video / GPU: | - NVIDIA GeForce RTX 5070Ti Blackwell 2.0; 12GB GDDR7; 5888 CUDA/184 Tensor cores
- NVIDIA Advanced Optimus Dynamic Display Switching Mode
- NVIDIA Surround View via 1x HDMI and 2x Thunderbolt 4.0 ports
|
| Built-in PC Camera: | Windows 5.0 FHD Hello Camera w/ Face Recognition Support
with Camera Shutter |
| LCD Size: | 16in / 40.64cm |
| LCD Specifications: | 16in QHD 240Hz 2560x1600; UHD 200Hz3840x2400; 16:10; 100% DCI-P3; eDP |
| Memory: | Two 262-pin; DDR5; SODIMM sockets; dual channel
DDR5-5600/5200/4800; up to 128GB |
| Total Storage: | 3x M.2 2280 NVMe slots for SSDs (2x PCIe 4.0 x4; 1x PCIe 5.0 x4)
RAID 0/1/5 |
| Card Reader: | 1x micro SD Card Reader supports microSD, microSDHC and microSDXC |
| Audio Architecture: | High Definition audio interface
Built-in Array Microphone
Built-in two speakers
Sound Blaster Studio Pro 2 |
| LAN/WLAN/Bluetooth: | - One 2.5 Gigabit Ethernet Intel/Killer E3100X; on-board; 1x RJ-45
- WLAN / Bluetooth via M.2 2230 slot
- Supports Killer Double Shot technology
|
| Security: | Kensington Lock
TPM 2.0 on-board
BIOS Password |
| Internal cards / # of slots/Type: | 4x M.2 slots
-1x: for WLAN + Bluetooth M.2 2230; PCIe
-3x: for NVMe SSD; 4x M.2 2280 (1x PCIe 5.0 + 2x PCIe 4.0)
|
| I/O Ports: | *** Total 9 I/O Ports ***
2 x USB 3.2 Gen2 ports (type A; 1x powered AC/DC)
2 x Thunderbolt 4 Type C with Power Delivery DC-in (from dGPU)
1 x HDMI 2.0 output(with HDCP (from dGPU
1 x 2-in-1 Audio jack (Headphone/Microphone)
1x RJ45 LAN port
1x microSD Reader
1x DC-in |
| Internal Keyboard: | - Built in Secure Pad with Microsoft PTP; multi-gesture and scrolling functionality
- Full size and colour illuminated LED "per key" keyboard with numeric pad |
| AC Adapter: | 230W; 100-240V 50-60Hz Auto-switching (worldwide)
optional 780W for Extreme Performance |
| Battery: | 8cells; Polymer; 80Wh
|
| Weight: | 2.25kg / 4.96lbs |
| Dimensions WxDxH: | 355.8mm x 271mm x 19.9mm / 14” x 10.67” x 0.78”
|
| Thickness: | 19.9mm / 0.78” |
