| Launch Date: | March 30, 2023 (13900HX)
January 31, 2024 (14900HX) |
| Special Feature(s): | Intel HM770 Express Chipset; i9-13900HX/14900HX 24C/32T; NVIDIA GeForce RTX 4090 (16GB DDR6); RAID 0/1/5; up to 96GB DDR5 |
| Main Chipset: | Intel HM770 Main Chipset
Intel Maple Ridge JHL8540 Thunderbolt Controller |
| Processor: | Intel i9-13900HX; 24C/32T; on-board
Intel i9-14900HX; 24C/32T; on-board
|
| Video / GPU: | - NVIDIA GeForce RTX 4090; 16GB DDR6; 9728 cores; on-board
- NVIDIA GeForce RTX 4080; 12GB DDR6; 7424 cores; on-board
- NVIDIA Advanced Optimus Dynamic Display Switching Mode
- Supports dGPU and iGPU for PhySX
- Supports total 5 Active Displays
- Supports NVIDIA Surrond View
- NVIDIA Virtual Reality |
| Built-in PC Camera: | Dual Sensor Windows 2.0 FHD Hello Camera with TNR |
| LCD Size: | 17.3in / 43.9cm |
| LCD Specifications: | 17.3in QHD 240Hz, UHD 144Hz; eDP
Optional G-Sync
|
| Memory: | Two 262-pin; DDR5; SODIMM sockets; dual channel
up to DDR5-5600; up to 96GB |
| Total Storage: | 3x M.2 2280 NVMe slots for SSDs (2x PCIe Gen4 x4; 1x PCIe Gen5 x4)
RAID 0/1/5 |
| Optical Drive: | External USB based
DVD-RW or Blu Ray Burner
|
| Audio Architecture: | High Definition Audio Interface
S/PDIF Optical / Mic/ Output to Dolby AC-3compatible receiver for 5.1 or DTS surround sound.
Built in array microphone
Built in two speakers
Sound Blaster Studio PRO
Audio Amplifier on headphone output |
| LAN/WLAN/Bluetooth: | - 2.5 Gigabit Ethernet Intel/Killer E3100X;on-board; RJ-45
- WLAN / Bluetooth; via M.2 2230 slot
|
| Security: | Kensington Lock
TPM 2.0 on-board
BIOS Password |
| Internal cards / # of slots/Type: | 4x M.2 slots
-1x: WLAN + Bluetooth M.2 2230; PCIe x2
-3x: M.2 2280; NVMe SSD
|
| I/O Ports: | *** Total 10 I/O Ports ***
2 x USB 3.2 Gen2 ports (type A; 1x powered)
1 x Thunderbolt 4 combo with Power Delivery DC-in
1 x Thunderbolt 4
1 x Mini DisplayPort 1.4
1 x HDMI 2.0 output (with HDCP)
1 x 2-in-1 Audio jack (Headphone/Microphone)
1 x 2-in-1 Audio jack (Microphone/SPDIF Optical output)
1 x RJ-45 LAN
1 x DC- |
| Internal Keyboard: | - Built in Secure Pad with Microsoft PTP; multi-gesture and scrolling functionality
- Full size and colour illuminated LED "per key" keyboard with numeric pad |
| AC Adapter: | 330W; 100-240V 50-60Hz Auto-switching (worldwide)
optional 780W for Extreme Performance |
| Battery: | 8cells; Polymer; 99Wh
|
| Weight: | 3.29kg / 7.24lbs |
| Dimensions WxDxH: | 396x278x24.9mm / 15.65x10.79x0.98in
|
| Thickness: | 0.98in / 24.9mm |
