| Launch Date: | March 5, 2017 |
| Special Feature(s): | NVIDIA GTX 1070 with 8GB DDR5 and G-Sync support
4 Active Displays
Aluminium Alloy Body |
| Main Chipset: | Intel HM175 Express Chipset |
| Processor: | Intel Mobile i7-7700HQ/7820HK series
Kaby Lake (14nm); onboard / SMT |
| Video / GPU: | GPU-onboard (SMT)
NVDIA GeForce GTX 1070; 8GB DDR5
MUX design (switchable between dGPU and iGPU)
Optional G-Sync support
|
| Built-in PC Camera: | Built-in 2M FHD Webcam |
| LCD Specifications: | 15.6" (39.62cm) LED backlit; eDP
FHD (1920x1080) 60Hz or 120Hz; 4K UltraHD (3840x2160) 60Hz
up to 4 active internal and/or external displays
NVIDIA Surrond View (HDMI 2.0 + miniDP 1.3) |
| Memory: | Four 204-pin SODIMM sockets
DDR4-2400/2666, 1.2V, 260pin
up to 64GB |
| Total Storage: | up to 4 physical drives:
- 2x M.2 2280 SSD SATA3 6Gb/s (or 1x M.2 2280 PCIe 2x/4x SSD + 1x M.2 SATA3 SSD) and
- 2x HDD/SSD SATA3 6Gb/s (1x 7mm and 1x 9.5/7.5mm) |
| Optical Drive: | External USB based
DVD-RW or Blu Ray Burner
|
| Card Reader: | 6-in-1 Push-Push Card Reader
MMC/RSMMC; SD/mini SD/SDHC/SDXC |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in array microphone
Built in two 2W speakers
Sound Blaster X-FI MB5
External 5.1CH output (Mic and Line-out)
ESS Sabre HiFi DAC high resolution headphone output) |
| LAN/WLAN/Bluetooth: | - 10/100/1000 LAN; Realtek RTL8111G
- WLAN/Bluetooth via M.2 2230 slot
- Prewired for 3G/4G/LTE M.2 |
| Security: | Kensington Lock
Fingerprint
TPM 2.0 on-board (Infineon SLB9665 TCG) |
| Internal cards / # of slots/Type: | Three M.2 slots
-1st for WLAN M.2 2230 Card with PCIe x2 and USB interface (A key)
-2nd for SSD M.2 2280 Card with SATA / PCIe x2/x4 SSD (M key)
-3rd for SSD M.2 2280 Card with SATA SSD or for LTE/UMTS/HSPA + M.2 3042 with USB interface (B key)
|
| I/O Ports: | 2 x USB 3.1 type C
3 x USB 3.0 (1x powered USB port, AC/DC)
2 x mini Display Port 1.3
1 x HDMI output
1 x 2-in-1: Headphone / SPDIF Optical output
1 x Microphone-in
1 x Line-out
1 x RJ-45 LAN
1 x DC-in |
| Internal Keyboard: | Backlit full size multi-colour (7-colours) keyboard with separate numeric pad
TouchPad with multi-gesture and scrolling (Synaptics TM-01474-003)
W/A/S/D Gaming key |
| AC Adapter: | 230W 100-240V 50-60Hz Auto-switching (worldwide)
DC Output 19.5V, 11.8A |
| Battery: | 4cells Polymer; 60WH; internal
up to 325 minutes in UMA mode |
| Weight: | 2.6kg / 5.72lbs w/ battery |
| Dimensions WxDxH: | 385x271x28.8mm / 15.16x10.66x1.13-inch |
| Shipping / Packaging L xWx H / N.W. / G.W.: | 22x13x5 inch / 11lbs; 550x330x120mm / 5kg
|
