| Launch Date: | May 1, 2021 |
| Special Feature(s): | Intel Z590 Chipset; PCIe 4.0 architecture; LGA1200 socket 10th and 11th gen CPUs; NVIDIA GeForce RTX 30x0 MXM 3.1 V2.0 GPUs PCIe 4.0 |
| Main Chipset: | Intel Z590 chipset
Intel Maple Ridge JHL8540 Thunderbolt Controller |
| Processor: | Socket LGA 1200
up to i9-10900K (PCIe 3.0)
up to i9-11900K (PCIe 4.0) |
| Video / GPU: | - one MXM 3.1 REV 2.0 slot; PCIe 4.0
- NVIDIA GeForce: RTX 3080 (16GB DDR6); RTX 3070 (8GB DDR6); RTX 3060 (6GB DDR6)
|
| Built-in PC Camera: | Built-in 1M |
| LCD Size: | 17.3in / 43.9cm |
| LCD Specifications: | 17.3" FHD 300Hz, UHD 60Hz; eDP
Optional G-Sync
|
| Memory: | Four 260-pin, 1.2V, SODIMM sockets
DDR4-2666/2933/3000/3200/3600; up to 128GB |
| Total Storage: | Four physical M.2 drives:
- 3x M.2 2280 NVMe PCIe Gen3 x4
- 1x M.2 2280 NVMe PCIe Gen4 x4 |
| Optical Drive: | External USB based
DVD-RW or Blu Ray Burner
|
| Card Reader: | 1x microSD Card Reader |
| Audio Architecture: | High Definition Audio
S/PDIF Output (optical)
Built in noise cancelling microphone
Built in 2.1 Speaker System
T1 Smart Amp
Creative Super X-Fi Ultra DSP chip
Creative Sound Blaster Atlas
ESS SABRE HiFi DAC for high res headphone output |
| LAN/WLAN/Bluetooth: | - WLAN / Bluetooth; M.2 2230 slot
- 2.5 Gigabit Ethernet RJ-45 LAN on-board; Killer E3000
- supports Killer DoubleShot Pro (with Killer WLAN) |
| Security: | Kensington Lock
Fingerprint
TPM 2.0 on-board |
| Internal cards / # of slots/Type: | Five M.2 slots
-1x: WLAN M.2 2230; PCIe x2
-4x; M.2 NVMe SSD
|
| I/O Ports: | 2 x Thunderbolt 4.0; type C (requires PCIe 4.0 based CPU such as 11900K) Intel JHL8540
1 x USB-C 3.2 Gen2
3 x USB-A 3.2 Gen2
2 x miniDP 1.4
1 x HDMI 2.0 output (with HDCP)
1 x 2-in-1 Audio jack (Headphone/Microphone)
1 x 2-in-1 Audio jack (Microphone/SPDIF Optical output)
1 x RJ-45 LAN
2 x DC-in |
| Internal Keyboard: | - RGB Keyboard with individual key illumination
N-Key-Rollover and Anti-Ghosting
- Microsoft Precision Touchpad with multi-gesture two buttons |
| AC Adapter: | 2x 280W; 100-240V 50-60Hz Auto-switching (worldwide)
optional 780W for Extreme Performance |
| Battery: | 8cells Smart Li-Ion; 97Wh
Easy to change |
| Weight: | 3.8kg / 8.36lbs |
| Dimensions WxDxH: | 399x319x44mm / 15.96x12.76x1.76in
|
| Thickness: | 1.76in / 44mm |
