| Launch Date: | June 15, 2019 |
| Special Feature(s): | World's first 17.3in laptop with RTX 2070 GPU and i9-9980HK (8C/16T) CPU
|
| Main Chipset: | Intel HM370 Express Chipset |
| Processor: | Intel Mobile i7-9750H (6C/12T) or i9-9980HK (8C/16T)
on-board (SMT) |
| Video / GPU: | GPU-onboard (SMT)
NVDIA GeForce RTX 2070; 8GB GDDR6 |
| Built-in PC Camera: | Built-in 1M Webcam |
| LCD Size: | 17.3in / 43.9cm |
| LCD Specifications: | 17.3in (43.9) LED backlit; eDP
FHD @ 144Hz
up to 4 active internal and/or external displays
NVIDIA Surrond View (HDMI 2.0 + 2x miniDP 1.3)
|
| Memory: | Two 260-pin SODIMM sockets
DDR4-2400/2666/3000, 1.2V, 260pin
up to 64GB |
| Total Storage: | up to 3 physical drives:
- 2x M.2 2280 NVMe
- 1x HDD/SSD SATA3 6Gb/s (2.5in 7mm) |
| Optical Drive: | External USB based
DVD-RW or Blu Ray Burner
|
| Card Reader: | 6-in-1 Push-Push Card Reader
MMC/RSMMC; SD/mini SD/SDHC/SDXC |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in array microphone
Built in two 2W speakers
SoundBlasterX Pro Gaming 360 (AL1220)
External 5.1CH output (Mic and Line-out)
ESS Sabre HiFi DAC high resolution headphone output) |
| LAN/WLAN/Bluetooth: | - 10/100/1000 LAN; Realtek RTL8111G
- WLAN/Bluetooth via M.2 2230 slot |
| Security: | Kensington Lock
Fingerprint on Glass
TPM 2.0 on-board (Infineon SLB9665 TCG) |
| Internal cards / # of slots/Type: | Three M.2 slots
-1st for WLAN M.2 2230 PCIe x2
-2nd for M.2 2280 SATA and/or PCIe x4 NVMe SSD
-3rd for M.2 2280; PCIe x4; NVMe SSD
|
| I/O Ports: | 1 x Thunderbolt 3 (USB 3.1C)
3 x USB 3.0 (1x powered USB port, AC/DC)
2 x mini Display Port 1.3 (1x via TB3)
1 x HDMI 2.0 output
1 x 2-in-1 Audio Jack (Headphone/Microphone)
1 x 2-in-1 Audio Jack (Microphone / SPDIF)
1 x RJ-45 LAN
1 x DC-in |
| Internal Keyboard: | - Backlit full size RGB multi-colour keyboard with separate numeric pad
- Gamma Secure Pad |
| AC Adapter: | 230W 100-240V 50-60Hz 19.5V 11.8A Auto-switching (worldwide)
|
| Battery: | 6cells Smart Li-Ion; 62WH; internal
up to 420 minutes in UMA mode |
| Weight: | 2.9kg / 6.38lbs |
| Dimensions WxDxH: | 399x275x29.9mm / 15.7x10.8x1.18in
|
| Thickness: | 1.18in / 29.9mm |
