15.6" (39.62cm); FHD (1920x1080) 60Hz / 120Hz or UHD (3840x2160) 60Hz; eDP LCD Heavy Duty Mechanical Design Chassis: Aluminium Alloy (Back Cover and Top Case) and German manufactured resins (Front Cover and Bottom Case) Weight: 2.92kg / 6.45 lbs w/ battery Chipset: Intel C236 Processor: XEON E3-1200 V5/V6 series; socket based; LGA1151; up to 91W TDP LAN Adapter: 1GbE on board; Qualcomm/Atheros E2500 Memory: up to 64GB; four 260-pin SODIMM sockets; DDR4-2133/2400/3000 Storage: up to 24TB of storage with 3 physical drives: 2x M.2 PCIe x2/x4 (NVMe) or SATA SSD and 1x HDD/SSD (9.5mm) SATA3 6Gb/s RAID Technology: RAID 0/1 with 2x NVMe SSDs VGA Technology: upgradeable MXM 3.0; NVIDIA Quadro: M1000M, M3000M, M4000M, M5000M, P3000, P4000 or P5000; up to 150W TDP; discrete GPU only (no Optimus) Display Support: up to 4 active displays including internal LCD; up to 3840x2160 @ 60Hz; Quadro via HDMI port supported @ 4K/30Hz or QHD/60Hz Card Reader: 6-in-1: UHS-II interface; MMC/RSMMC/SD/mini SD/SDHC/SDXC; Push-Push Keyboard and Touchpad: Anti-ghosting backlit multi-colour 7-colour keyboard with seperate numeric keypad; TouchPad with multi-gesture and scrolling; W/A/S/D Gaming key Ports: 3x USB 3.0; 1x USB 3.1 type C (Thunderbolt 3); 1x miniDP 1.2; 1x HDMI 2.0; 1x Headphone; 1x Microphone-in; 1x S/PDIF (digital); 1x Line-in; 1x RJ-45 LAN; 1x DC-in Audio: High Definition Audio; S/PDIF Digital Output; Built in microphone; Built in two 2W speakers; Sound Blaster X-FI MB3; External 7.1CH output (headphone, mic, line-in and S/PDIF). Display Support: up to 4 active displays including internal LCD; up to 3840x2160 @ 60Hz Battery: 8cells; 14.4V 5225mAh/75.24Wh Li-Ion; up to 130 minutes Dimensions: 390x266x39.8mm / 15.6x10.64x1.59-inch

Configure

Specs

Images

Videos

Brochure

Benchmarks

Reviews

Components

User Manual

Upgrade

Drivers

FAQs

Base Configuration   Display Calibration   Choose from the options below Professional Display Calibration with .icc Profile Saved on USB Flash Key [$71]   Choose your LCD Display   Choose from the options below 15.6in (39.6cm); 60Hz FHD 1920x1080; Matte; IPS; C/R 700:1; 300cd/m2; NTSC 72%; eDP; 30pin; LG LP156WF6-SPB1 [$143] 15.6in (39.6cm); UHD; 60Hz; Matte; PLS; 700:1; 16ms; NTSC 72%; eDP; 40pin; Samsung LTN156FL02-101 [$334]   Processor / CPU   Choose from the options below 3.3GHz (up to 3.9GHz) Intel Core i5-6600; 4C/4T; 6MB; 14nm; LGA1151; 65W [$316] 3.4GHz (up to 4GHz) Intel Core i7-6700; 4C/8T; 8MB; 14nm; LGA1151; 65W [$396] 4GHz (up to 4.2GHz) Intel Core i7-6700K; 4C/8T; 8MB; 14nm; LGA1151; 91W [$476] 3.6GHz (up to 4.2GHz) Intel Core i7-7700; 4C/8T; 8MB L3; 14nm; LGA1151; 65W; Intel D Graphics 630 [$476] 4.2GHz (up to 4.5GHz) Intel Core i7-7700K; 4C/8T; LGA1151; 91W [$799]   Memory Configuration   Choose from the options below 16GB; 2x 8GB; DDR4-2400; 260-pin; 1.2V; 2 SODIMMs; Micron [$264] 16GB; 1x 16GB; DDR4; 2666Hz; CL15; 260-pin;1.2V; Kingston HyperX; 1 SODIMM [$320] 16GB; 1x 16GB; DDR4-2400; 260-pin; 1.2V; 1 SODIMM; G-Skill F4-2400C16S-16GRS [$320] 16GB; 2x 8GB; DDR4-2400; CL14; 260-pin; 1.2V; Kingston HyperX; 2 SODIMMs [$312] 16GB; 1x 16GB; DDR4-3000; Corsair; 260-pin; 1.2V; 1 SODIMM [$336] 32GB; 2x 16GB; DDR4-2400; 260-pin; 1.2V; 2 SODIMMs; G-Skill F4-2400C16S-16GRS [$640] 32GB; 4x 8GB; DDR4-2400; CL17; 260-pin; Micron; 1.2V; 4 SODIMMs [$528] 32GB; 2x 16GB; DDR4; 2666Hz; CL15; 260-pin;1.2V; Kingston HyperX; 2 SODIMMs [$640] 32GB; 2x 16GB; DDR4-2400; CL14; 260-pin Kingston HyperX; 1.2V; 2 SODIMMs [$640] 32GB; 2x 16GB; DDR4-3000; Corsair; 260-pin; 1.2V; 2 SODIMMs [$672] 64GB; 2x 32GB; DDR4-2666; 260-pin; 1.2V; 2 SODIMMs; Micron/Crucial/Samsung [$1152] 64GB; 4x 16GB; DDR4-2400; 260-pin; 1.2V; 4 SODIMMs; G-Skill F4-2400C16S-16GRS [$1120] 64GB; 4x 16GB; DDR4-2400; CL14; 260-pin; Kingston HyperX; 1.2V; 4 SODIMMs [$1120] 64GB; 4x 16GB; DDR4-3000; Corsair; 260-pin; 1.2V; 4 SODIMMs [$1344]   BIOS: Standard or Unlocked   Choose from the options below UNLOCKED BIOS [$143]   3D Devices for Precision Engineering   Choose from the options below 3Dconnexion CadMouse for Precision Engineering [$159] 3Dconnexion SpaceMouse Enterprise for Precision Engineering; 3DX-700056 [$559] 3Dconnexion SpaceMouse Pro Wireles for Precision Engineering; 3DX-700075 [$639]   eXpansion Modules for 2-3 External Monitors   Choose from the options below Matrox TripleHead2Go DisplayPort Edition; w/ 3 DP-out ports; up to 3 external displays; 5760x1080 (3x 1920x1080) or 3840x1200 (2x 1920x1200) [$399]   GPU Technology   Choose from the options below   VGA / GPU Graphics Options   Choose from the options below Quadro M2000M; 4GB GDDR5; N16P-Q3; 640 CUDA; MXM 3.0a; 55W [$636] Quadro M3000M; 4GB GDDR5; N16E-Q1; 1024 CUDA; MXM 3.0b; 28nm; 75W [$796] Quadro M4000M; 4GB GDDR5; N16E-Q3; 1280 CUDA; MXM 3.0b; 100W [$1356] Quadro M5000M; 8GB GDDR5; N16E-Q5; 1536 CUDA; MXM 3.0b; 28nm; 100W [$1996] Quadro P3000; 6GB GDDR5; N17E-Q1; 1280 CUDA; MXM 3.1; 82x105mm; 75W [$1196] Quadro P4000; 8GB GDDR5; N17E-Q3; 1792 CUDA; MXM 3.1B; 82x105mm; 100W [$1519] Quadro P5000; 16GB GDDR5; N17E-Q5; 2048 CUDA; MXM 3.1b; 82x105mm; 100W [$2239] Quadro P3200; 6GB GDDR5; N18E-Q1; 1792 CUDA; MXM 3.1; 75W [$1196] NVIDIA GeForce GTX 1060; 6GB DDR5; 1280 CUDA; N17E-G1; MXM 3.1b; 82x105mm; 75W [$499] 8GB GDDR5X; NVIDIA GeForce GTX 1080; 2560 CUDA; N17E-G3; MXM 3.1; up to 150W [$1199]   Thermal Paste: GPU Heatsink   Choose from the options below IC Diamond 7 Carat Thermal Compound for Maximum Performance [$55] Grizzly Kryonaut; Ultra High Performance Thermal Grease [$79]   Thermal Paste; CPU Heatsink   Choose from the options below IC Diamond 7 Carat Thermal Compound for Maximum Performance [$55] Grizzly Kryonaut; Ultra High Performance Thermal Grease [$79]   Operating System(s)   Choose from the options below Microsoft Windows Server 2012 R2 x64 Standard; OEM Edition; w/ 5 CTL User CAL [$1119] Microsoft Windows 10 Home; 64-bit; OEM; USB key [$159] Microsoft Windows 10 Professional; 64-bit; OEM; with DVD and USB key [$299] Microsoft Windows 7 Professional 64-bit; OEM; with DVD and USB key [$319] Microsoft Windows Server 2016 Standard; OEM Edition; w/ 5 CTL User CAL [$1199] Microsoft Windows Server 2016 Standard; OEM Edition; w/ 1 CTL User CAL [$879] Microsoft Windows Server 2022 x64 Standard; OEM; w/ 1 CTL User CAL [$1359] Microsoft Windows Server 2022 x64 Standard; OEM; w/ 5 CTL User CALs [$1759] Linux Ubuntu 24.04 installed; USB key [$91]   Keyboard (Language)   Choose from the options below US English; QWERTY; Backlit [$135] Español / Spanish; QWERTY; Backlit [$135] Alemán / German; QWERTZ; Backlit [$135] Italiana / Italian; QWERTY; Backlit [$135] Français / French; AZERTY; Backlit [$135] Russian Latin; QWERTY; Backlit [$135] UK English; QWERTY; Backlit [$135]   Business Productivity Software   Choose from the options below Microsoft Office 2024 Home and Student Edition; OEM; MLK; US/Canada [$143] Microsoft Office 2024 Home and Business Edition; OEM; MLK; US/Canada [$279]   RAID Configuration   Choose from the options below RAID 0 - for maximum performance; at least 2 physical drives are required [$76] RAID 1 - for redundancy; at least 2x physical drives are required [$76]   Internal PCIe NVMe M.2 SSD   Choose from the options below 250GB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [$135] 250GB; M.2; SSD; NVMe 1.4; PCIe 3.0 x4; R/W: 3500/3000 MB/s; SAMSUNG 980 [$135] 500GB; M.2; SSD; NVMe 1.4; PCIe 3.0 x4; R/W: 3500/3000 MB/s; SAMSUNG 980 [$319] 500GB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [$263] 500GB; M.2 SAMSUNG 980 Pro; SSD; PCIe 4.0; NVMe; R/W: up to 7000/5100MB/s [$399] 1TB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [$559] 1TB SSD; SAMSUNG 990 Pro; PCIe Gen 4.0 x4, NVMe 2.0; M.2 2280; R/W up to 7,450/6,900 MB/s [$879] 1TB; SSD; PCIe 4.0 x4 / 5.0 x2 NVMe; M.2; R/W: up to 5000/4200 MB/s; SAMSUNG 990 EVO [$719] 2TB SSD; SAMSUNG 990 Pro; PCIe Gen 4.0 x4, NVMe 2.0; M.2 2280; R/W: up to 7000/5100 MB/s [$999] 2TB; M.2 SAMSUNG 970 EVO; SSD; NVMe; R/W: 3500/2500 MB/s [$999] 4TB SSD; PCIe Gen 4.0 x4, NVMe 2.0; M.2; 22x80mm; Samsung 990 Pro; AES 256-bit Encryption [$1299] 8TB; M.2 NVMe SSD; 22x80mm; Sabrent Rocket Q; 5.7g/2.4oz [$1999]   Internal PCIe NVMe M.2 SSD   Choose from the options below 250GB; M.2; SSD; NVMe 1.4; PCIe 3.0 x4; R/W: 3500/3000 MB/s; SAMSUNG 980 [$135] 500GB; M.2; SSD; NVMe 1.4; PCIe 3.0 x4; R/W: 3500/3000 MB/s; SAMSUNG 980 [$319] 500GB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [$263] 500GB; M.2 SAMSUNG 980 Pro; SSD; NVMe; R/W: up to 7000/5100MB/s [$399] 1TB SSD; SAMSUNG 990 Pro; PCIe Gen 4.0 x4, NVMe 2.0; M.2 2280; R/W up to 7,450/6,900 MB/s [$879] 1TB SSD; PCIe Gen 4.0 x4, NVMe 2.0 ; M.2 2280; R/W: up to 5000/4200 MB/s; SAMSUNG 990 EVO [$719] 1TB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [$559] 2TB SSD; SAMSUNG 990 Pro; PCIe Gen 4.0 x4, NVMe 2.0; M.2 2280; R/W: up to 7000/5100 MB/s [$999] 2TB; M.2 SAMSUNG 970 Evo; NVMe PCIe 3.0 x4; SSD; R/W: 3500/2500 MB/s [$999] 4TB SSD; PCIe Gen 4.0 x4, NVMe 2.0; M.2; 22x80mm; Samsung 990 Pro; w/ AES 256-bit Encryption [$1299] 8TB; M.2 NVMe SSD; 22x80mm; Sabrent Rocket Q; 5.7g/2.4oz [$1999]   RAID Options: HDD/SSD Storage   Choose from the options below RAID 0 setup - for maximum performance; minimum 2 physical drives are required [$60] RAID 1 setup - for full fault tolerance; minimum 2 physical hard drives are required [$60] Multiple Partitions with One O/S - please specify size of each partition [$60] Multiple Partitions with Two O/S; please specify size of each partition; order 2nd O/S [$60]   1st Drive: HDD, SSD or SSHD   Choose from the options below 1TB; 7200rpm; SATA3; Seagate BarraCuda Pro; ST1000LM049; 7mm 2.5in [$180] 1TB; HDD; SATA3; 5400rpm; Seagate Barracuda ST1000LM048; 7mm; 2.5in [$180] 2TB; HDD; SATA3; Seagate BarraCuda ST2000LM015; 2.5in 7mm [$316] 256GB SSD; MLC; Micron/Crucial; M1100; SATA3 6Gb/s; 7mm [$212] 250GB SSD; SATA3; 2.5in; 7mm; Samsung 870 EVO; R/W 560/530 MB/s [$276] 480GB SSD; MLC; Intel DC S3510; SATA3 6Gb/s; R/W: 500/440 MB/s; 7mm 2.5-inch [$476] 512GB SATA3 SSD; MLC; Micron M1100 SATA3 (6Gb/s); 7mm [$436] 500GB SSD; SATA3; 2.5in; 7mm; Samsung 870 EVO; R/W: 560/530 MB/s [$479] 800GB SSD; MLC; Intel DC S3510; SATA3 6Gb/s; 7mm; R/W: 500/440 MB/s [$796] 1TB SSD; SATA3; Micron 1100; 7mm; 2.5in [$559] 1TB SSD; Samsung 870 Evo; SATA3; 7mm; 2.5in; MZ-77E1T0B/AM [$559] 1TB SSD; SATA3; 2.5in; 7mm; Samsung 860 Pro [$719] 2TB SSD; SATA3; 2.5in; 7mm; Samsung 860 Pro [$1279] 2TB SSD; Samsung 870 Evo; SATA3; 7mm; 2.5in; R/W: 560/530 MB/s [$959] 4TB SSD; Samsung 870 Evo; SATA3; 7mm; 2.5in; R/W: 560/530 MB/s [$1759] 8TB SSD; Micron 5100 Enterprise; SATA3; R/W (MB/s): 540 / 520; 2.5in; 7mm [$3999] *** Without Hard Drive; with HDD bracket included *** [$126]   External Optical Drive   Choose from the options below External; 6x Blu Ray (BD-RW) Burner; Pioneer BDR-XD05B; USB 3.0 [$319] 24x DVD-RW; External; USB 2.0 [$119]   Internal Card Reader   Choose from the options below   Security Cables / Devices:   Choose from the options below Targus - Defcon CL Cable PA410C [$39] Targus Defcon 1 Alarm Device PPA400C [$39]   Security - ANTI SPYING Package   Choose from the options below Physical Removal of internal Webcam, Microphone and WLAN/Bluetooth Module [$95] Physical Removal of internal Webcam and Microphone. [$66]   Wireless LAN   Choose from the options below 2-in-1: 802.11ac WLAN+Bluetooth 5; Intel Wireless-AC 9260; M.2 2230; up to 1.73Gbps [$111] 2-in-1; 802.11a/b/g/n/ac WLAN + Bluetooth 4.1; Killer Wireless-AC 1535 [$79] 2-in-1: 802.11a/b/g/n/ac WLAN+Bluetooth 4.2; Intel Wireless-AC 8265; M.2 2230; up to 867Mbps; 2.4GHz/5GHz [$79] 2-in-1; 802.11ac WLAN + Bluetooth 5; Killer Wireless-AC 1550 [$111] None, without WLAN module installed [$63]   TV Tuner (Internal and/or External)   Choose from the options below External USB 2.0 TV Tuner; KWORLD UB445 ATSC HYBRID w/REMOTE [$79]   Add Extra LAN Port(s):   Choose from the options below 1GbE USB 3.0 to 1GbE (1x RJ45 port) Adapter; Startech [$86] USB-C to Dual Gigabit Ethernet Adapter; 2x RJ-45 ports; Startech US1GC301AU2R; VIA/VLI VL817 / ASIX AX88179A [$143]   Built-in Web Camera   Choose from the options below 2.0 Megapixels; Webcam; Built-in [$55] Without Webcam installed [$47]   HDMI Port(s)   Choose from the options below   Thunderbolt Port   Choose from the options below   Standard Battery (internal)   Choose from the options below 8-cells Lithium-lon Battery; Easy to change [$143]   Choose Extra Battery   Choose from the options below 8-cells Lithium-lon Battery; Easy to change [$143] 2pcs of 8-cells Smart Li-Ion Battery [$286]   Standard Power Cord - included   Choose from the options below USA / Canada [$7] EUROPE [$7] UK [$7] SOUTH AFRICA [$7] AUSTRALIA [$7]   Standard AC Adapter   Choose from the options below 230W; 100V-250V; Auto-Switching (Worldwide) [$116] 280W AC Adapter; Auto switching;100-240V; Round Plug; 2.2lbs/1kg; 7.25x3.25x1.5in/185x80x35mm [$159] 330W AC Adapter; Auto-switching; 100-240V; 50-60Hz; DC 19.5V @ 16.9A [$180] 780W AC Adapter; 110V-250V Auto Switching; 3lbs/1.3kg; 12.8x4.3x1.6in/325x110x40mm; with DC cable [$448]   Extra Power Cord   Choose from the options below 1 Extra; USA/CANADA [$7] 2 Extra; US/CANADA [$14] 1 Extra; UK [$7] 1 Extra; EUROPE [$7] 1 Extra; SOUTH AFRICA [$7] 1 Extra; AUSTRALIA [$7] 2 Extra; AUSTRALIA [$14] 2 Extra; SOUTH AFRICA [$14] 2 Extra, EUROPE [$14] 2 Extra; UK [$14]   Choose Extra AC Adapter   Choose from the options below 230W; Auto-switching 100V-250V [$116] 2 extra 230W AC Adapters; 100V-250V [$232] 280W AC Adapter; Auto switching;100-240V; Round Plug; 2.2lbs/1kg; 7.25x3.25x1.5in/185x80x35mm [$159] 330W AC Adapter; 100-240V; w/ 4pin round plug [$180] 2 extra 330W AC Adapters; Auto-switching; 100-250V [$360] 30W AC Adapter; 100-240V Auto-Switching; 19V; 1.58A; T890M [$56]   Carrying Case   Choose from the options below 16in Targus Trademark Notepac Plus Case; Black (CTM400); internal: 14.5x2x11.75in [$103] 16in Sport Backpack; Heavy-Duty Fabrics with Nylon Webbing Reinforcement; TARGUS TCG650 [$95] 17.3in Sport Backpack; Black; Targus Voyager TSB953GL [$135] 18.4in EVERKI ContemPRO; XXL Backpack; EKP117B; 530x420x220mm [$239] 18in (43.1-45.7cm); Black; Clamshell; Targus CNXL18 Laptop Pro Case [$151] 17in Rolling Travel Case; Black Nylon; Exterior 457x381x254mm / 18.28x15.24x10.16in; Targus TCG717 [$103]   Choose Your Warranty Plan   Choose from the options below 2 Years Return to Factory Depot with 2 Years of Tech Support [$220] 3 Years Return to Factory Depot with 3 Years of Tech Support [$335] Options   Extra Thermal Pads for M.2; VRAM; RAM   Choose from the options below Set of M.2 SSD Thermal pads 45x19x8mm for Tornado F5/F7 [$28]   Graphics Tablet / Stylus   Choose from the options below Wacom Intuos Pro;Small; 10.6x6.7in (active 6.3x3.9in); Pen Tablet; PTH460K0A [$319] Wacom Intuos Pro - Medium; 13.2x8.5in (active 8.7x5.8in); Pen Tablet; PTH660 [$399] Wacom Intuos Pro - Large; 16.8x11.2in (active 12.1x8.4in); Pen Tablet; PTH860 [$559] Accessories   Docking Stations, Hubs and Port Replicators   Choose from the options below USB 3.0 Hub; 4 Ports; Black Colour; Startech ST4300USB3; 55g/1.94oz [$63] Universal USB-C DV4K Docking Station; w/ 65W AC Adapter; Black; Targus DOCK310USZ [$319]   Car Adapters and Inverters   Choose from the options below 700W Portable Power Inverter; 3 AC Outlets (US); Tripplite; 12V AC/60Hz; 12V DC, 1.26kg; 70x207.5x126mm [$143] 375W DC-to-AC Portable Power Inverter; 2 AC Outlets (US); TRIPP-LITE PV375; US Edition; 120V AC/60Hz; 12V DC; 2.2lbs [$95]   Cables, Converters and Adapters   Choose from the options below 1 Port USB to Serial RS232 / DB9 Adapter Cable with Optical Isolation; FTDI - FT232RL; Startech ICUSB2321FIS [$159] 2pcs DisplayPort to DVi-I Converter Cables for Matrox TH2G or DH2G DP Edition [$46] 1pc DisplayPort to DVi-I Converter Cable for DP port and/or Matrox DH2G or TH2G DP Edition [$23] 10ft (3m) HDMI to DVI-D Cable M/M; HDMIDVIMM10 [$55]   Cables/Adapters for External Monitors; DP; mDP; HDMI; DVI   Choose from the options below MiniDP to DVI Dual-Link Active Adapter – USB Powered; MDP2DVID [$183] HDMI or DVI to DP Active Converter (converts HDMI, DVI or Mini DVI input into a DP output); HDMI2DP [$103] 10ft (3m) MiniDP to DP Cable; M/M; MDP2DPMM10 [$55] 6-inch MiniDP to DP cable; M/F; MDP2DPMF6IN [$39]
