Launch Date: | June 31, 2025 |
Main Chipset: | Mobile Intel HM870 Express Chipset |
Processor: | Intel Core Ultra 9, 275HX 24C/24T/36M cache; on-board |
Video / GPU: | NVIDIA GeForce RTX 5060 Blackwell; 4608 CUDA; 144 Tensor cores; 8GB GDDR7 Switchable Hybrid Graphics between iGPU/dGPU or dGPU only Supports up to 4 active displays (3x external + 1x internal LCD) |
Built-in PC Camera: | 1.0M video camera |
LCD Specifications: | 17.3in LED backlit; eDP; FHD; 144Hz |
Memory: | Two 262-pin DDR5-5600/4800 SODIMM sockets up to 128GB |
Total Storage: | up to 3 physical drives: - 3x M.2 2280 SSD via M.2 PCIe 4.0 x4 Supports RAID 0/1/5 |
Optical Drive: | External via USB port
|
Audio Architecture: | High Definition Audio Built in array microphone Built in two speakers Sound Blaster Studio + |
LAN/WLAN/Bluetooth: | -Built in PCIe Gigabit Base-TX Ethernet LAN; Realtek RTL8168/8111 -WLAN /Bluetooth via M.2 2230 slot with PCIe / USB / CNVi interface |
Security: | Kensington Lock Intel PTT TPM |
Internal cards / # of slots/Type: | Four M.2 slots -1st for WLAN; M.2 2230 Card with PCIe / USB / CNVi interface (E key) -2nd for SSD M.2 2280 PCIe 4.0 x4; NVMe -3rd for SSD M.2 2280; PCIe 4.0 x4 NVMe -4th for SSD M.2; 2280; PCIe 4.0 x4 NVMe
|
I/O Ports: | • 1 x HDMI output port (with HDCP) • 1 x DisplayPort 2.1 over USB 3.2 Gen2 port (Type C) • 1 x DisplayPort 2.1 over USB 3.2 Gen2 port (Type c) w/ power delivery DC-in • 1 x USB 3.2 Gen2 port (Type A) • 1 x USB 3.2 Gen1 port (Type A) • 1 x 2-in-1 Audio jack (Headphone / Microphone) • 1 x DC in |
AC Adapter: | 100~240V, 50~60Hz, DC output 20V, 11.5A, 230W
|
Battery: | Internal 4 cells Polymer battery pack, 73WH
|
Weight: | 2.7kg / 5.95lbs
|
Dimensions WxDxH: | 397x265.1x24.9-28.6mm / 15.88x10.6x0.996-1.144in
|
Thickness: | 24.9mm/0.996in |
