Launch Date: | August 10, 2024 |
Special Feature(s): | VPro TPM 2.0 MIL-STD 810H |
Processor: | Intel Core Ultra 7 Processor 155H; 16T/22C Intel Core Ultra 5 Processor 125H; 14C/18T |
Video / GPU: | Intel Arc graphics iGPU with AI Boost – Ray Tracing – Variable Rate Shading – Microsoft DirectX® 12 compatible – Intel® DLBoost: DP4A |
Built-in PC Camera: | Built-in 2M FHD Webcam |
LCD Size: | 14.0" FHD+ 1920x1200; 16:10 16.0" FHD+ 1920x1200; 16:10 |
LCD Specifications: | FHD+; 1920x1200; 60Hz
|
Memory: | Two 262-pin DDR5 SODIMM sockets up to 96GB |
Total Storage: | up to 2 physical drives: - 2x M.2 2280 NVME slots; PCIe Gen4x4 - RAID 0/1 |
Card Reader: | • Micro SD Push-Push Card reader |
Audio Architecture: | • High Definition Audio • Built in array microphone, can be removed together with the camera • Built in two speakers
|
LAN/WLAN/Bluetooth: | 1GbE Ethernet LAN on-board;RJ-45; Realtek RTL8168/8111 M.2 2230 slot for WLAN/Bluetooth; PCIe/USB/CNVi interface
|
Security: | Kensington Lock TPM 2.0 on-board VPro |
Internal cards / # of slots/Type: | Three M.2 card slots -1st for WLAN M.2 2230; PCIe/USB/CNVi -2nd for M.2 2280 SSD NVMe;PCIe Gen4x4 -3rd for M.2 2280 SSD NVMe;PCIe Gen4x4
|
I/O Ports: | • 1 x Thunderbolt 4 combo port with Power Delivery DC in (Type C) and Display Alt Mode (DP 2.1) support • 1 x USB 3.2 Gen 2 port with Power Delivery DC in (Type C) • 1 x USB 3.2 Gen 2 port (Type A, powered USB port) • 1 x USB 3.2 Gen 1 port (Type A) • 1 x HDMI output port (version 2.1 with HDCP) • 1 x 2-in-1 Audio Combo Jack (Headphone / Microphone) • 1 x RJ-45 LAN port • 1 x DC-in jack |
AC Adapter: | 90W 100-240V 50-60Hz Auto-switching (worldwide) 5"x2"x1" / 0.75lb; 125x50x25mm / 340g |
Battery: | Standard Polymer Li-Ion 36WH (5h) or optional high capacity 73WH (10h)
|
Weight: | • 317 x 235 x 18 mm / 12.68 x 9.4 x 0.72in • 1.6kg/3.52lbs |
