Launch Date: | August 20, 2022 |
Special Feature(s): | World's first 17.3in laptop with Intel's HM670 PCIe 4.0 Mobile Chipset
|
Main Chipset: | Intel HM670 Express Chipset; PCIe 4.0 |
Processor: | Intel i7-12700H; 14C/20T; 24MB cache; on-board Intel i9-12900H; 14C/20T; 24MB cache; on-board |
Video / GPU: | - NVDIA GeForce RTX 3070 Ti (8GB DDR6) or RTX 3080 Ti (16GB DDR6); on-board - Intel IRIS Xe Graphics; 1GB; iGPU - Microsoft Hybrid Graphics Mode - Supports NVIDIA Surround View via HDMI; mDP and DP |
Built-in PC Camera: | Built-in 1M Webcam |
LCD Size: | 17.3in / 43.9cm |
LCD Specifications: | 17.3in (43.9) LED backlit; eDP FHD @ 144Hz; QHD @ 165Hz; UHD @ 60Hz up to 5 active displays |
Memory: | Two 260-pin SODIMM sockets DDR4-3200, 1.2V, 260pin up to 64GB |
Total Storage: | up to 2 physical drives: - 2x M.2 2280 SSD via M.2 PCIe 4.0 x4 - RAID 0/1 |
Optical Drive: | External USB DVD-RW or Blu Ray Burner
|
Card Reader: | MicroSD Push-Push Card Reader
|
Audio Architecture: | Stereo Speakers Smart Amplifier Optical S/PDIF-out Microphone with noise cancelling Sound Blaster Atlas |
LAN/WLAN/Bluetooth: | - 1 Gigabit Ethernet NIC; Realtek RTL8168/8111; on-board - WLAN/Bluetooth via M.2 2230 slot |
Security: | Kensington Lock TPM 2.0 |
Internal cards / # of slots/Type: | Three M.2 slots -1st for WLAN M.2 2230 PCIe x2; CNVI -2nd for M.2 2280 PCIe 4.0 x4; NVMe -3rd for M.2 2280; PCIe 4.0 x4 NVMe
|
I/O Ports: | Rear: - Mini DP 1.4 - HDMI-out - Thunderbolt 4.0 (Type C) - Dc-in Left: - USB 3.2 Gen 1 (Type A) - Powered USB 3.2 Gen 1 (Type A) - 2-in1 Audio Jack (Headphone/Microphone) - 2-in-1 Audio Jack (Microphone / SPDIF Optical) Right: - MicroSD Card Reader - DisplayPort 1.4 over USB 3.2 Gen 2 Type C - LAN RJ-45 |
Internal Keyboard: | - Backlit full size keyboard with separate numeric pad - Microsoft Precision Touchpad, two integrated buttons; 119x71mm |
AC Adapter: | 230W / 280W / 330W
|
Battery: | Li-Polymer battery; 80Wh; internal |
Weight: | 2.8kg /6.16lbs |
Dimensions WxDxH: | 396x262x24.9mm / 15.5x10.5x0.99in
|
Thickness: | 24.9mm/0.99in |
