15.6in UHD 60Hz or FHD 60Hz, 120Hz, 144Hz

  • Platform: Coffee Lake Intel HM370; NVIDIA MAX-Q design 18.6mm thin
  • Powerful Processor: Intel Core i7-8750H (6cores/12threads); on-board
  • GPU Technology: NVIDIA GeForce GTX 1070 (8GB DDR5); on-board; Microsoft Hybrid Graphics mode
  • Display Technology: supports total 4 active displays; supports NVIDIA Surround View via HDMI x1 and miniDP x2.
  • Robust Design: Titanium Black Aluminum Alloy (AL-5052): back cover, top case and bottom case.
  • Cooling: High performance, high quality copper GPU and CPU heatsinks to keep your system running cool.
  • Memory: Two 260-pin SODIMM sockets; DDR4-2400/2666/3000; 1.2V; up to 64GB
  • Storage: up to 10TB of storage with 2 physical drives: 1x M.2 2280 SSD SATA3 / PCIe x4 and 1x HDD/SSD SATA3 6Gb/s and RAID 0/1
  • Communications: 1GbE LAN, WLAN (M.2) and optional LTE/4G M.2 module (built-in antenna and SIM socket)
  • Sound System: SoundBlasterX Pro Gaming 360; ALC1220
  • Card Reader: 6-in-1: MMC/RSMMC/SD/mini SD/SDHC/SDXC; Push-Push
  • Keyboard and Touchpad: Backlit multi-colour full size 7-colour keyboard with numeric pad; TouchPad with multi-gesture and scrolling; W/A/S/D Gaming key
  • Loaded with Ports: 2x USB 3.1c; 3x USB 3.0; 2x mini Display Port 1.3; HDMI 2.0 output; 2-in-1 Audio Jack (Headphone + S/PDIF output); Microphone-in; RJ-45 LAN; DC-in
  • Operating Systems: Windows 10
  • Security: Kensington Lock, Fingerprint and Embedded TPM 2.0 Encryption
  • Battery: 4cells Lithium Polymer; 55WH; up to 300 minutes in UMA mode
  • Weight: 1.9kg / 4.2lbs
  • Dimensions: WxDxH: 380x249x18.6mm / 15.2x9.96x0.74-inch
    CustomizeSpecificationsImagesBrochureBenchmarksReviewsPrice ListComponentsUser ManualDriversUpgradeUpgrade Price List
    Launch Date:May 1, 2018
    Special Feature(s):18.6mm MAX-Q Design with NVIDIA GTX 1070 8GB
    Aluminium Alloy Body
    Main Chipset:Intel HM370 Express Chipset
    Processor:Intel Mobile i7-8750H; 6C/12T; on-board
    Video / GPU:GPU-onboard (SMT)
    NVDIA GeForce GTX 1070; 8GB DDR5
    Built-in PC Camera:Built-in 2M FHD Webcam
    LCD Size:15.6in / 39.62cm
    LCD Specifications:15.6" (39.62cm) LED backlit; eDP
    FHD (1920x1080) 60Hz, 120Hz, 144Hz; UHD (3840x2160) 60Hz
    up to 4 active internal and/or external displays
    NVIDIA Surrond View (HDMI 2.0 + 2x miniDP 1.3)
    HDMI and DP ports are prewired to dGPU for maximum performance
    Memory:Two 260-pin SODIMM sockets
    DDR4-2400/2666/3000, 1.2V, 260pin
    up to 64GB
    Total Storage:up to 2 physical drives:
    - 1x M.2 2280 PCIe 2x/4x/SATA and
    - 1x HDD/SSD SATA3 6Gb/s (2.5inch 7mm)
    Optical Drive:External USB based
    DVD-RW or Blu Ray Burner
    Card Reader:6-in-1 Push-Push Card Reader
    Audio Architecture:High Definition Audio
    S/PDIF Digital Output
    Built in array microphone
    Built in two 2W speakers
    SoundBlasterX Pro Gaming 360 (AL1220)
    External 5.1CH output (Mic and Line-out)
    ESS Sabre HiFi DAC high resolution headphone output)
    LAN/WLAN/Bluetooth:- 10/100/1000 LAN; Realtek RTL8111G
    - WLAN/Bluetooth via M.2 2230 slot
    - Prewired for 3G/4G/LTE M.2
    Security:Kensington Lock
    TPM 2.0 on-board (Infineon SLB9665 TCG)
    Internal cards / # of slots/Type:Three M.2 slots
    -1st for WLAN M.2 2230 PCIe x2
    -2nd for SSD M.2 2280 SATA / PCIe x2/x4 SSD
    -3rd for LTE/UMTS/HSPA M.2 3042
    I/O Ports:2 x USB 3.1 type C
    3 x USB 3.0 (1x powered USB port, AC/DC)
    2 x mini Display Port 1.3
    1 x HDMI 2.0 output
    1 x 2-in-1: Headphone / SPDIF Optical output
    1 x Microphone-in
    1 x RJ-45 LAN
    1 x DC-in
    Internal Keyboard:Backlit full size multi-colour (7-colours) keyboard with separate numeric pad
    TouchPad with multi-gesture and scrolling (Synaptics TM-01474-003)
    W/A/S/D Gaming key
    AC Adapter:150W 100-240V 50-60Hz 19V 7.89A Auto-switching (worldwide)
    Optional 180W
    Battery:4cells Polymer; 55WH; internal
    up to 400 minutes in UMA mode
    Weight:1.9kg / 4.2lbs
    Dimensions WxDxH:380x249x18.6mm / 15.2x9.96x0.74-inch
    Thickness:0.74in / 18.6mm
    Shipping / Packaging L xWx H / N.W. / G.W.:22x13x5 inch / 11lbs; 550x330x120mm / 5kg
