EUROCOM SKY M5 R2
15.6-inch 4K QFHD IPS 3840-by-2160 or FHD IPS 1920-by-1080 pixels; 60Hz; eDP; LED Backlit

  • Processor: on-board; Intel Core i7-6700HQ (Skylake); 6M Cache
  • VGA Technology: on-board; NVIDIA GeForce GTX 1060 (6GB DDR5); G-Sync; MUX design (switchable between dGPU and iGPU)
  • Mechanical (Frame):brushed aluminium (back cover and bottom case) combined with heavy duty ABS plastic (front cover and top case).
  • Cooling: High performance, high quality copper VGA and CPU heatsinks to keep your system running cool.
  • Memory: Four 260-pin SODIMM sockets; DDR4-2133/2400; 1.2V; up to 64GB
  • Storage: up to 6TB of storage with 4 physical drives: 2x M.2 2280 SSD SATA3 / PCIe x4 and 2x HDD/SSD SATA3 6Gb/s and RAID 0/1
  • Communications: 1Gb LAN, WLAN, built in antenna for optional 3G/4G/LTE/HSPA
  • Card Reader: 6-in-1: MMC/RSMMC/SD/mini SD/SDHC/SDXC; Push-Push
  • Keyboard and Touchpad: Backlit multi-colour full size 7-colour keyboard with numeric pad; TouchPad with multi-gesture and scrolling; W/A/S/D Gaming key
  • Ports: 2x USB 3.1 Type C; 3x USB 3.0; 2 x mini Display Port 1.3; 1 x HDMI output; 2-in-1 Headphone + S/PDIF; 1 x Microphone-in; 1 x RJ-45 LAN; 1 x DC-in
  • Display Support: Supports up to 4 active internal and/or external displays
  • Operating Systems: Windows 10, 8.1 and 7
  • Security: Embedded TPM 2.0 Encryption; Fingerprint and Kensington Lock
  • Battery: 4cells Polymer; 60WH; up to 325 minutes in UMA mode
  • Weight: 2.6kg / 5.72lbs
  • Dimensions: WxDxH: 385x271x25.4mm / 15.16x10.66x1.02-inch
  •
    CustomizeSpecificationsImagesBrochureReviewsPrice ListComponentsUser ManualDriversUpgradeUpgrade Price List
    Launch Date:October 10, 2016
    Special Feature(s):NVIDIA GTX 1060 with 6GB DDR5 and G-Sync support
    up to 4 Active Simultaneous Displays
    Aluminium Alloy Body
    Main Chipset:Intel HM170 Express Chipset
    Processor:Intel Mobile i7-67xxHQ/68xxHK series
    Skylake (14nm); onboard / SMT
    Video / GPU:GPU-onboard (SMT)
    NVDIA GeForce GTX 1060 (N16E-G1); 6GB DDR5
    MUX design (switchable between dGPU and iGPU)
    G-Sync support
    Built-in PC Camera:Built-in 2M FHD Webcam
    LCD Specifications:15.6" (39.62cm) LED backlit; eDP
    IPS FHD (1920x1080) @60Hz; 4K QFHD+ (3840x2160)@ 60Hz
    supports up to 4 active internal and/or external displays
    supports NVIDIA Surrond View (HDMI 2.0 + miniDP 1.3)
    Memory:Four 260-pin SODIMM sockets; DDR4-2133/2400, 1.2V
    up to 64GB
    Total Storage:up to 4 physical drives:
    - 2x M.2 2280 SSD SATA3 6Gb/s
    (or 1x M.2 2280 PCIe x4/x2 SSD and 1x M.2 SATA3 SSD) and
    - 2x HDD/SSD SATA3 6Gb/s (2x 7mm or 1x 9.5mm)
    Optical Drive:External DVD-RW or Blu Ray Burner; via USB port
    Card Reader:6-in-1 Push-Push Card Reader
    MMC/RSMMC
    SD/mini SD/SDHC/SDXC
    Audio Architecture:High Definition Audio
    S/PDIF Digital Output
    Built in array microphone
    Built in two 2W speakers
    Sound Blaster X-FI MB3
    External 5.1CH output (microphone and Line-out)
    ANSP 3D Sound technology with headphone output
    LAN/WLAN/Bluetooth:- 10/100/1000 LAN; Realtek RTL8111G
    - WLAN/Bluetooth via M.2 2230 slot
    - Optional 3G/4G/LTE module via M.2 3042 slot (built-in SIM socket and antenna)
    Security:Kensington Lock
    Fingerprint
    TPM 2.0 on-board (Infineon SLB9665 TCG)
    Internal cards / # of slots/Type:Three M.2 card slots
    -1st for WLAN M.2 2230 Card with PCIe x2 and USB interface (A key)
    -2nd for SSD M.2 2280 Card with SATA / PCIe x2/x4 SSD (M key)
    -3rd for SSD M.2 2280 Card with SATA SSD or for LTE/UMTS/HSPA + M.2 3042 with USB interface (B key)
    I/O Ports:2 x USB 3.1 Type C
    3 x USB 3.0 (1x powered USB port, AC/DC)
    2 x mini Display Port 1.3
    1 x HDMI 2.0 output
    1 x 2-in-1 Audio: Headphone + S/PDIF
    1 x Microphone-in
    1 x Line-out
    1 x RJ-45 LAN
    1 x DC-in
    Internal Keyboard:Backlit full size 7-colours keyboard with separate numeric pad
    TouchPad with multi-gesture and scrolling (Synaptics TM-01474-003)
    W/A/S/D Gaming key
    AC Adapter:200W 100-240V; 19V; 10.5A 50-60Hz Auto-switching (worldwide)
    Battery:4cells Polymer; 60WH; internal
    up to 325 minutes in UMA mode
    Weight:2.6kg / 5.72lbs w/ battery
    Dimensions WxDxH:385x271x25.4mm / 15.16x10.66x1.02-inch
    Shipping / Packaging L xWx H / N.W. / G.W.:22x13x5 inch / 11lbs; 550x330x120mm / 5kg
