| Launch Date: | January 6, 2016 |
| Special Feature(s): | NVIDIA GTX 970M; 3GB DDR5
4 Active Displays
Aluminium Alloy Body |
| Main Chipset: | Intel HM170 Express Chipset |
| Processor: | Intel Mobile i7-67xxHQ/68xxHK series
Skylake (14nm); onboard / SMT |
| Video / GPU: | GPU-onboard (SMT)
NVDIA GeForce GTX 970M; 3GB DDR5
Microsoft Hybrid Graphics or dGPU mode
Supports four active displays |
| Built-in PC Camera: | Built-in 2M FHD Webcam |
| LCD Size: | 14in (35.56cm) |
| LCD Specifications: | 14" (35.56cm) LED backlit; eDP; 3mm; IPS FHD (1920x1080) or QHD (2560x1440)
supports up to 4 active internal and/or external displays
supports NVIDIA Surrond View (HDMI 2.0 + miniDP 1.2) |
| Memory: | Two 260-pin SODIMM sockets; DDR4; 1.2V
up to 64GB |
| Total Storage: | up to 2 physical drives:
- one M.2 2280 PCIe x4/x2 / SATA3 SSD
- one HDD/SSD SATA3 6Gb/s (7mm) |
| Optical Drive: | External USB based; DVD-RW or Blu Ray Burner
|
| Card Reader: | 6-in-1 Push-Push Card Reader
MMC/RSMMC/SD/mini SD/SDHC/SDXC |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in array microphone
Built in two 2W speakers
Sound Blaster X-FI MB5
External 5.1CH output (headphone, mic and S/PDIF)
ANSP 3D Sound Technology (headphone output) |
| LAN/WLAN/Bluetooth: | - 10/100/1000 LAN; Realtek RTL8111G
- WLAN/Bluetooth via M.2 2230 slot
- Prewired for 3G/4G/LTE (optional M.2 module) |
| Security: | Kensington Lock
TPM 2.0 on-board (Infineon SLB9665 TCG) |
| Internal cards / # of slots/Type: | Three M.2 card slots
-1st for WLAN M.2 2230 Card with PCIe x2 and USB interface (A key)
-2nd for SSD M.2 2280 Card with SATA/PCIe x2/x4 SSD (M key)
-3rd for LTE/UMTS/HSPA + M.2 3042 with USB interface (B key)
|
| I/O Ports: | 4 x USB 3.0 (1x powered USB port, AC/DC)
2 x mini Display Port 1.2
1 x HDMI output
1 x Headphone
1 x Microphone-in
1 x S/PDIF (digital)
1 x RJ-45 LAN
1 x DC-in |
| Internal Keyboard: | Backlit keyboard
TouchPad with multi-gesture and scrolling (Synaptics TM-01474-003)
W/A/S/D Gaming key |
| AC Adapter: | 180W 100-240V 50-60Hz Auto-switching (worldwide)
|
| Battery: | 3cells Polymer; 45WH; internal
up to 290 minutes in UMA mode |
| Weight: | 2kg (4.4lbs) |
| Dimensions WxDxH: | 349x247x25.4mm |
| Thickness: | 25.4mm (1.0in) |
