| Launch Date: | December 15, 2015 |
| Special Feature(s): | Intel Z170 Chipset; Skylake-S; supports both mobile and a desktop based GTX 980 GPU |
| Main Chipset: | Intel Z170 (Skylake) |
| Processor: | Socket LGA 1151
Skylake-S; up to i7-6700K, unlocked
|
| Video / GPU: | - MXM 3.0 slot; up to 180W GPU
- NVDIA GeForce GTX 980 (desktop) N16E-GXX MXM 3.0 (83x 115mm)or GTX 980M, 970M, 965M; MXM 3.0b (83x105mm) |
| Built-in PC Camera: | Built-in 2M FHD |
| LCD Specifications: | 17.3" UHD IPD eDP 3840x2160
Supports 4 active displays
|
| Memory: | Four 260-pin, 1.2V, SODIMM sockets
DDR4-2133/2400; up to 64GB |
| Total Storage: | up to 4 physical drives:
- 2x M.2 2280 SSD PCIe Gen3 2x/4x or SATA
- 2x 2.5" 9.5mm/7mm HDD/SSD/SHDD
- RAID 0/1/5/10 |
| Optical Drive: | External USB based
DVD-RW or Blu Ray Burner
|
| Card Reader: | 6-in-1 Push-Push Card Reader
MMC/RSMMC SD/mini SD/SDHC/SDXC
UHS-II (SD 4.0) |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in array microphone
Built in two 2W speakers and subwoofer
Sound Blaster X-FI MB5
External 7.1CH output (headphone, mic, line-in and S/PDIF)
ANSP 3D Sound Technology (headphone output) |
| LAN/WLAN/Bluetooth: | - WLAN / Bluetooth; M.2 2230 slot
- 1Gigabit Ethernet RJ-45 LAN on-board; Killer E2400 |
| Security: | Kensington Lock
Fingerprint
TPM 2.0 on-board (Infineon SLB9665-TCG) |
| Internal cards / # of slots/Type: | Three M.2 slots
-1st: WLAN M.2 2230 Card with PCIe x2 and USB (A Key)
-2nd for SSD M.2 2280 Card with SATA / PCIe x2/x4 (M key)
-3rd for SSD M.2 2280 Card with SATA / PCie x2/x4 (M key)
|
| I/O Ports: | 1 x USB 3.1 type C / Thunderbolt 3 / DP 1.2 / HDMI 2.0
3 x USB 3.0
1 x eSATA / USB 3.0 (1x Powered USB AC/DC)
2 x miniDisplay Port 1.2
1 x HDMI 2.0 output
1 x Headphone
1 x Microphone-in
1 x S/PDIF (digital)
1 x Line in
1 x RJ-45 LAN
1 x DC-in |
| Internal Keyboard: | Backlit full size keyboard with numeric pad
TouchPad with multi-gesture and scrolling
W/A/S/D Gaming key |
| AC Adapter: | 330W 100-240V 50-60Hz Auto-switching (worldwide)
optional 660W (2x 330W) for Extreme Performance |
| Battery: | 8cells Smart Li-Ion; 89W
FexiCharger (via BIOS) |
| Weight: | 3.9kg / 8.58lb with battery |
| Dimensions WxDxH: | 418x295x39.9mm / 16.72x11.81x1.6-inch
|
