15.6-inch FHD 1920-by-1080 pixels; 16:9 panel; 3.8mm; eDP; LCD can be open up to 180 degrees.
Chipset: Intel Q370; vPro Technology LAN Adapter: 1GbE on-board (Intel I219) Processor: up to 2.9GHz; socket LGA1151; Intel i7-8700T, i7-8700, i5-8600, i5-9600K, i7-9700K Memory: up to 64GB; DDR4-2666; SODIMM; two 260-pin sockets GPU Controller: Intel HD Graphics 630; iGPU Storage: up to 24TB of storage; three drives (2nd HDD/SSD via ODD bay, 3rd via M.2) Optical Drive: choice of DVD-RW or Blu-RW; internal ODD Operating System: Microsoft: Windows 10, Server 2016; Linux; VMware ESXI Audio: Built in two 2W speakers; built in microphone; S/PDIF output Keyboard: LED illuminated keyboard; built in touchpad with multi-gesture and scrolling function I/O Ports: 1x Thunderbolt 3; 2x USB 3.0 (1x powered USB); 1x USB 2.0; 1x HDMI out; 1x VGA; 1x 2-in-1 Audio Jack (Headphone / S/PDIF); 1x Mic; 1x RJ-45 Docking Station Port:optional hot docking station available SmartCard Reader: built in SmartCard Reader (Alcor Micro AU9560-GBS-GR) Card Reader: MMC/RSMMC/SD/mini SD/SHDC/SDXC Communications: built in 1Gb LAN (Intel I219 vPro); M.2 WLAN; prewired for LTE/4G M.2 WAN module Power: 65W, 120W or 150W AC Adapter 100-250V; 6-cell 62WH Smart Li-Ion batteries (340 minutes) Security: TPM 2.0; Kensington Lock; Fingerprint Reader Dimensions and Weight: 382x259.5x32.95mm; 15.28x10.38x1.32-inch; 2.5kg/5.5lbs
Docking Station: Dimensions and Weight: 380x206x33mm/15.2x8.24x1.32-inch; 0.85kg/1.87lb I/O Ports: 3x USB 2.0; 4x USB 3.0 (including 1x powered); 1x CRT; 1x DVI-D; 1x HDMI-out; 1x Headphone out; 1x Mic in; 1x S/PDIF; 1x RJ45/LAN; 1x RS232 (serial); 1x docking port; 1x DC-in, 1x Kensington Security Lock slot HDMI and DVI ports: support 1920x1080 FHD 60Hz external monitors only Storage: ODD (DVD-RW or Blu Ray) or HDD/SSD Power: external 90W AC Adapter provided |
