EUROCOM Tornado F5
15.6-inch FHD 1920-by-1080 pixels or 4K UHD 3840-by-2160 pixels

  • Fully upgradeable, fully customizable - a True Workhorse
    Turn the EUROCOM Tornado F5 into the laptop of your dreams by selecting the components you want to fit inside this highly capable, yet very mobile chassis.

  • Chassis: Aluminium Alloy (Back Cover and Top Case) and German manufactured resins (Front Cover and Bottom Case)
  • Chipset: High Performance Intel Z170 Express Chipset
  • Processor: Socket based; LGA1151; up to 91W TDP; choice of Core i7, i5, i3 up to 6700K/7700K.
  • VGA Technology: upgradeable MXM 3.0; NVIDIA GeForce: GTX 1080, 1070, 1060, 980M, 970M or 965M; Quadro: M1000M, M3000M, M4000M, M5000M, P3000, P4000 and P5000; up to 150W TDP; discrete GPU only (no Optimus)
  • Memory: Four 260-pin SODIMM sockets; DDR4-2133/2400/3000; up to 64GB
  • Storage: up to 16TB with 3 physical drives: 2x M.2 2280 PCIe x2/x4 or SATA SSD and 1x HDD/SSD (9.5mm) SATA3 6Gb/s; RAID 0/1 with 2x NVMe SSDs.
  • Card Reader: 6-in-1: UHS-II interface; MMC/RSMMC/SD/mini SD/SDHC/SDXC; Push-Push
  • Keyboard and Touchpad: Anti-ghosting backlit multi-colour 7-colour keyboard with seperate numeric keypad; TouchPad with multi-gesture and scrolling; W/A/S/D Gaming key
  • Ports: 3x USB 3.0; 1x USB 3.1 type C (Thunderbolt 3); 1x miniDP 1.2; 1x HDMI 2.0; 1x Headphone; 1x Microphone-in; 1x S/PDIF (digital); 1x Line-in; 1x RJ-45 LAN; 1x DC-in
  • Audio: High Definition Audio; S/PDIF Digital Output; Built in microphone; Built in two 2W speakers; Sound Blaster X-FI MB3; External 7.1CH output (headphone, mic, line-in and S/PDIF).
  • Display Support: Supports up to 4 active displays including internal LCD; up to 3840x2160 @ 60Hz
  • Battery: 8cells; 14.4V 5225mAh/75.24Wh Li-Ion; up to 130 minutes
  • Weight: 2.92kg / 6.45 lbs w/ battery
  • Dimensions: 390x266x39.8mm / 15.6x10.64x1.59-inch
    		•

    CustomizeSpecificationsImagesVideosBrochureBenchmarksReviewsPrice ListComponentsUser ManualDriversFAQsUpgradeUpgrade Price ListLCD Chart
    EUROCOM Tornado F5 Keyboard Options and Layouts
    Mar 02, 2017
    PDF Document

    The EUROCOM Tornado F5 supports 11 Keyboard languages including:
    -Arabic
    -Belgian
    -French
    -German
    -Italian
    -Nordic
    -Russian
    -Spanish
    -Turkish
    -US/International
    -United Kingdom

    How do I add a M.2 SSD w/ Termal Pad to Tornado F5?
    Dec 01, 2016

    If you would like to add a M.2 SSD Hard Drive to your system it is important that the correct process is used. If you install the M.2 drive without using the accompanied thermal pad, there is a chance your M.2 drive may overheat possibly damaging your M.2 drive and/or your notebook. Please look at the provided picture which shows the correct placement of the Thermal pad that come with your M.2 Hard drive.


    How do I get Tornado F5 series laptop to recognize and utilize CORSAIR DDR4 3000 Memory?
    Mar 21, 2017
    PDF Document

    The XMP1 BIOS profile in the EUROCOM Tornado F5 Unlocked BIOS is designed to allow DDR4-3000 CORSAIR memory to function at its peak performance, which is 3000 MHz. DDR4 2400 and 2666 memory is recognized and utilized without BIOS modification. This short document shows users how to set the XMP1 memory profile in their BIOS to recognize DDR4 3000 memory.

    How do I setup and use the S/PDIF port on Tornado F5 laptop?
    Sep 17, 2020
    PDF Document

    Trying to use the dual S/PDIF-Headphone jack as a S/PDF connection to your Home Theater? Here is the process to change the default headphone jack to a S/PDIF port.

    How do I toggle the power to my webcam on/off on Tornado F5?
    Mar 21, 2019

    In order to turn the power off and on to your Webcam, simply depress FN-F6. Every depression of this keystroke will power the Webcam Off and On...Off and On

    How to disable the Touchpad on Tornado F5 series laptop?
    Jun 16, 2017

    If you like you can disable the Touch pad on your Tornado F5. Simply select FN-F3 and it will toggle the Touch pad off and on.

    How to add RAM under the Keyboard in the Tornado F5
    Jan 25, 2017

    Here is a link to a Video that gives you step by step instructions on how to dis-assemble your Eurocom Tornado F5 to place RAM in the two RAM slots under the keyboard.

    64 GB DDR4 2400 Memory upgrade in EUROCOM Tornado F5 Gaming Laptop
