| Launch Date: | Dec 20, 2024 |
| Main Chipset: | Mobile Intel HM770 Express Chipset |
| Processor: | Intel Core i9-14900HX; 55W; 24C/32T; on-board |
| Video / GPU: | NVIDIA GeForce RTX 4070; 4608 CUDA; 144 Tensor cores; 8GB DDR6 or
NVIDIA GeForce RTX 4060; 3072 CUDA; 80 Tensor cores; 8GB DDR6
NVIDIA Advanced Optimus (Dynamic Display Switching) Technology
Supports up to 3 active displays |
| Built-in PC Camera: | 1.0M FHD video camera |
| LCD Size: | 17.3in |
| LCD Specifications: | 17.3in LED backlit; eDP; FHD; 144Hz |
| Memory: | Two 262-pin DDR5-5600/4800 SODIMM sockets
up to 128GB |
| Total Storage: | up to 3 physical drives:
- 3x M.2 2280 SSD via M.2 PCIe 4.0 x4 slots
Supports RAID 0/1/5 |
| Optical Drive: | External via USB port
|
| Audio Architecture: | High Definition Audio
Built in array microphone
Built in two speakers
Sound Blaster Studio + |
| LAN/WLAN/Bluetooth: | -Built in PCIe Gigabit Base-TX Ethernet LAN; Realtek RTL8168/8111
-WLAN /Bluetooth via M.2 2230 slot with PCIe / USB / CNVi interface |
| Security: | Kensington Lock
Intel PTT |
| Internal cards / # of slots/Type: | Four M.2 slots
-1st for WLAN; M.2 2230 Card with PCIe / USB / CNVi interface (E key)
-2nd for SSD M.2 2280 PCIe 3.0 x4; NVMe
-3rd for SSD M.2 2280; PCIe 4.0 x4 NVMe
-4th for SSD M.2; 2280; PCIe 4.0 x4 NVMe
|
| I/O Ports: | • 1 x USB 3.2 Gen2 port (Type c) with power delivery DC-in
• 1 x USB 3.2 Gen2 port (Type A)
• 1 x USB 3.2 Gen1 port (Type A)
• 1 x DisplayPort 1.4 over USB 3.2 Gen2 port (Type C)
• 1 x HDMI output port (with HDCP)
• 1 x 2-in-1 Audio jack (Headphone / Microphone)
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
| AC Adapter: | Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 20V, 11.5A, 230W
|
| Battery: | Internal 4 cells Polymer battery pack, 53.53WH
Battery life: 360 minutes (UMA mode) |
| Weight: | 2.7kg / 5.94lbs |
| Dimensions WxDxH: | 397x265.1x24.9 - 28.6mm / 15.88x10.6x0.996-1.144in
|
| Thickness: | 24.9 - 28.6mm/0.996 - 1.144in |
