| Launch Date: | Dec 1, 2022 |
| Special Feature(s): | World's first 15.6in laptop with LGA1700 socket Intel 12th gen CPU |
| Main Chipset: | Intel H670 |
| Processor: | Intel socket LGA1700
up to Intel i9 12900K;16C/24T |
| Video / GPU: | GPU-onboard
NVDIA GeForce RTX 3070Ti; 8GB GDDR6 or
NVIDIA GeForce RTX 3060 6GB GDDR6
|
| Built-in PC Camera: | Built-in Webcam |
| LCD Size: | 15.6in / 39.62cm |
| LCD Specifications: | 15.6" (39.62cm); eDP; FHD 240Hz; QHD 165Hz; UHD OLED 60Hz
up to 4 active internal and/or external displays
NVIDIA Surrond View (HDMI 2.0 + 2x miniDP 1.4)
|
| Memory: | Two 260-pin SODIMM sockets
up to DDR4-3200, 1.2V, 260pin
up to 64GB |
| Total Storage: | up to 3 physical drives:
- 2x M.2 2280 NVMe
- 1x HDD/SSD SATA3 (2.5in 7mm)
- RAID 0/1 |
| Optical Drive: | External USB based
DVD-RW or Blu Ray Burner
|
| Card Reader: | MicroSD Push Push Card Reader |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in array microphone
Built in two 2W speakers
SoundBlasterX Pro Gaming 360 (AL1220)
External 5.1CH output (Mic and Line-out)
ESS Sabre HiFi DAC high resolution headphone output) |
| LAN/WLAN/Bluetooth: | - 1 Gigabit Ethernet PCIe NIC; Realtek RTL8168/8111; on-board
- WLAN/Bluetooth via M.2 2230 slot |
| Security: | Kensington Lock
TPM 2.0 on-board (Infineon SLB9665 TCG) |
| Internal cards / # of slots/Type: | Three M.2 slots
-1st for WLAN M.2 2230 Module
-2nd for M.2 2280 SATA or PCIe x4 NVMe SSD
-3rd for M.2 2280; PCIe x4 NVMe SSD |
| I/O Ports: | 1x USB-A 2.0 (type) A
2x USB-A 3.2 Gen2 (type A)
1x Display Port 1.4 over USB 3.2 Gen 2 (type C)
1x Mini Display Port 1.4
1x HDMI 2.1 output (with HDCP)
1x 2-in-1 Audio Jack (Headphone/Microphone)
1x Mic-in jack
1x RJ-45 LAN
1x DC-in |
| Internal Keyboard: | - Backlit keyboard with numeric keypad
|
| AC Adapter: | 230W 100-240V 50-60Hz 19.5V 11.8A Auto-switching (worldwide)
|
| Battery: | 6cells Smart Li-Ion; 62WH; internal
|
| Weight: | 2.6kg / 5.7lbs |
| Dimensions WxDxH: | 361x258x32.5mm / 14.44x10.32x1.3-inch
|
| Shipping / Packaging L xWx H / N.W. / G.W.: | 22x13x5 inch / 11lbs; 550x330x120mm / 5kg
|
