| Launch Date: | October 30, 2021 |
| Special Feature(s): | World's first 15.6in OLED laptop with Intel's HM570 PCIe 4.0 Mobile Chipset
|
| Main Chipset: | Intel HM570 Express Chipset |
| Processor: | Intel i7-11800H; 8C/16T; 24MB cache
on-board |
| Video / GPU: | NVDIA GeForce RTX 3070; 8GB GDDR6 or RTX 3080; 16GB DDR6
on-board |
| Built-in PC Camera: | Built-in 1M Webcam |
| LCD Size: | 15.6in |
| LCD Specifications: | 15.6in LED backlit; eDP
UHD OLED or FHD 240Hz
up to 3 active external displays |
| Memory: | Two 260-pin SODIMM sockets
DDR4-2666/3000/3200, 1.2V, 260pin
up to 64GB |
| Total Storage: | up to 2 physical drives:
- 1x M.2 2280 SSD via M.2 PCIe 4.0 x4
- 1x M.2 2280 SSD via M.2 PCI3 3.0 x4
Supports RAID 0/1 |
| Optical Drive: | External via USB port
DVD-RW or Blu Ray Burner
|
| Audio Architecture: | Stereo Speakers
Smart Amplifier
S/PDIF-out (optical)
Microphone with noise cancelling
Sound Blaster Atlas |
| LAN/WLAN/Bluetooth: | - 1 Gigabit Ethernet NIC; Realtek RTL8168/8111; on-board
- WLAN/Bluetooth via M.2 2230 slot |
| Security: | Kensington Lock
Fingerprint
TPM 2.0 (via Intel PTT) |
| Internal cards / # of slots/Type: | Three M.2 slots
-1st for WLAN M.2 2230 PCIe x2
-2nd for M.2 2280 PCIe 3.0 x4; NVMe
-3rd for M.2 2280; PCIe 4.0 x4 NVMe
|
| I/O Ports: | Rear:
- Thunderbolt 4 / USB-c 3.2 Gen2 (DP)
- DC in
- HDMI 2.1 (with HDCP 2.3)
- Mini DP 1.4
Left:
- 2-in-1 Audio (Mic-in + S/PDIF optical)
- Headphone-out (smart headphone compatible)
- USB-A 3.2 Gen1 (powered
Right:
- RJ45 LAN
- 2x USB-A 3.2 |
| Internal Keyboard: | - Backlit full size RGB multi-colour keyboard with separate numeric pad
- Gamma Secure Pad |
| AC Adapter: | 180W; 145x75x23mm; 620g
|
| Battery: | Li Ion battery 73Wh; easy to change |
| Weight: | 2.0kg / 4.4lbs |
| Dimensions WxDxH: | 358x238x20mm / 14.32x9.52x0.8in
|
| Thickness: | 19.9mm/0.796in |
