Launch Date: | June 7, 2019 |
Special Feature(s): | World's first 15.6in OLED laptop with RTX 2070 GPU
|
Main Chipset: | Intel HM370 Express Chipset |
Processor: | Intel Mobile i7-9750H (6C/12T) or i9-9980HK (8C/16T); on-board |
Video / GPU: | GPU-onboard (SMT) NVDIA GeForce RTX 2070; 8GB GDDR6 or NVIDIA GeForce GTX 1660Ti; 6GB GDDR6 |
Built-in PC Camera: | Built-in 1M Webcam |
LCD Size: | 15.6in / 39.62cm |
LCD Specifications: | 15.6" (39.62cm) LED backlit; eDP UHD 60Hz OLED or FHD 144Hz IPS up to 4 active internal and/or external displays NVIDIA Surrond View (HDMI 2.0 + 2x miniDP 1.3)
|
Memory: | Two 260-pin SODIMM sockets DDR4-2400/2666/3000, 1.2V, 260pin up to 64GB |
Total Storage: | up to 3 physical drives: - 2x M.2 2280 NVMe - 1x HDD/SSD SATA3 6Gb/s (2.5in 7mm) |
Optical Drive: | External USB based DVD-RW or Blu Ray Burner
|
Card Reader: | 6-in-1 Push-Push Card Reader MMC/RSMMC; SD/mini SD/SDHC/SDXC |
Audio Architecture: | High Definition Audio S/PDIF Digital Output Built in array microphone Built in two 2W speakers SoundBlasterX Pro Gaming 360 (AL1220) External 5.1CH output (Mic and Line-out) ESS Sabre HiFi DAC high resolution headphone output) |
LAN/WLAN/Bluetooth: | - 10/100/1000 LAN; Realtek RTL8111G - WLAN/Bluetooth via M.2 2230 slot |
Security: | Kensington Lock Fingerprint on Glass TPM 2.0 on-board (Infineon SLB9665 TCG) |
Internal cards / # of slots/Type: | Three M.2 slots -1st for WLAN M.2 2230 Module -2nd for M.2 2280 SATA or PCIe x4 NVMe SSD -3rd for M.2 2280; PCIe x4 NVMe SSD |
I/O Ports: | 1 x Thunderbolt 3 (USB 3.1C) 3 x USB 3.0 (1x powered USB port, AC/DC) 2 x mini Display Port 1.3 (1x via TB3) 1 x HDMI 2.0 output 1 x 2-in-1 Audio Jack (Headphone/Microphone) 1 x 2-in-1 Audio Jack (Microphone / SPDIF) 1 x RJ-45 LAN 1 x DC-in |
Internal Keyboard: | - Backlit full size RGB multi-colour keyboard with separate numeric pad - Gamma Secure Pad |
AC Adapter: | 230W 100-240V 50-60Hz 19.5V 11.8A Auto-switching (worldwide)
|
Battery: | 6cells Smart Li-Ion; 62WH; internal up to 420 minutes in UMA mode |
Weight: | 2.5kg / 5.5lbs |
Dimensions WxDxH: | 380x249x18.6mm / 15.2x9.96x0.74-inch
|
Thickness: | 1.12in / 29.9mm |
Shipping / Packaging L xWx H / N.W. / G.W.: | 22x13x5 inch / 11lbs; 550x330x120mm / 5kg
|
