17.3in; UHD 60Hz; QHD 120Hz or FHD 60Hz, 120Hz, 144Hz

  • Chipset: Intel Z370 Express (Coffee Lake)
  • Processor: socketed desktop LGA1151 CPU, up to Intel i9-9900KS, 8cores/16threads, fully unlocked
  • Memory: up to 128GB; DDR4-2133/2400/2666/3000; 4 memory sockets (128GB option requires TB3 port to be disabled)
  • GPU Technology: NVIDIA GeForce: GTX 1080, 1070 and 2060; RTX 2080, 2070 and 2060; Quadro P5000, P4000 and P3000; MXM 3.1 slot; up to 190W; GPU upgradeable
  • Display Technology: supports 4 monitors
  • Storage: up to 32TB with 4 drives; 2x HDD/SSD (SATA3) + 2x M.2 PCIe Gen3 x4/NVMe/SATA3; RAID 0/1/5/10; supports Intel Optane technology
  • Communications: 1Gb LAN RJ-45 port Killer E2500 + M.2 WLAN/Bluetooth
  • Operating Systems: Microsoft Windows 10, Microsoft Server 2018, Linux/Ubuntu
  • Card Reader: 6-in-1 MMC/RSMMC/SD/miniSD/SDHC/SDXC up to UHS-II
  • Keyboard: Illuminated, backlit with customizable 7-colours
  • Loaded with Security: TPM 2.0, BIOS Disk encryption, Fingerprint and Kensington Lock
  • Audio System: Sound Blaster X Pro-Gaming 360˚; external 7.1CH audio output; headphone out, microphone in, S/PDIF and Line-in port; two built-in ONKYO Speakers (2.2W)+ Subwoofer (2.5W)
  • Ports: 1x USB 3.1 Gen2 / Thunderbolt3 combo port (Type-C); 2x miniDP 1.3; 1x HDMI 2.0; 3x USB 3.0 ; 1x USB 3.0 (Powered USB, AC/DC); S/PDIF; Headphone; Mic; Line-in; RJ45 (LAN)
  • Weight and dimensions: 3.9kg / 8.58lb; WxDxH 418x295x39.9mm / 16.72x11.81x1.6-inch
    CustomizeSpecificationsImagesBrochureBenchmarksReviewsPrice ListComponentsUser ManualDriversFAQsUpgradeUpgrade Price ListLCD Chart
    Launch Date:November 15, 2017
    Special Feature(s):Intel Z370 Chipset; Coffee Lake-S LGA1151 CPUs
    Main Chipset:Intel Z370 (Coffee Lake)
    Processor:Socket LGA 1151
    Coffee Lake: up to i9-9900KS; 8C/16T
    supports both 8th and 9th gen of CPUs
    Video / GPU:- one MXM 3.1 slot; up to 190W GPU
    - NVIDIA GeForce: GTX 1080, 1070, 1060
    - NVIDIA GeForce: RTX 2080, 2070, 2060
    - NVIDIA Quadro: P5000, P4000, P3000
    Built-in PC Camera:Built-in 2M FHD
    LCD Size:17.3in / 43.9cm
    LCD Specifications:17.3" FHD, QHD; UHD; 60Hz/120Hz/144Hz; eDP
    Supports 4 active displays @ 4K 60Hz
    Optional G-Sync
    Memory:Four 260-pin, 1.2V, SODIMM sockets
    DDR4-2400/2666/3000; up to 128GB
    Total Storage:up to 4 physical drives:
    - 2x M.2 2280 SSD PCIe Gen3 2x/4x/SATA RAID0/1
    - 2x 2.5" 9.5mm/7mm HDD/SSD/SHDD RAID 0/1
    Supports Intel Optane technology via M.2 slot
    Optical Drive:External USB based
    DVD-RW or Blu Ray Burner
    Card Reader:6-in-1 Push-Push Card Reader
    UHS-II (SD 4.0)
    Audio Architecture:High Definition Audio
    S/PDIF Digital Output
    Built in array microphone
    Built in two 2W speakers (Foster) and subwoofer
    Sound Blaster X Pro-Gaming 360°
    ESS SABRE HiFi DAC for high res headphone output
    LAN/WLAN/Bluetooth:- WLAN / Bluetooth; M.2 2230 slot
    - 1Gigabit Ethernet RJ-45 LAN on-board; Killer E2500
    Security:Kensington Lock
    TPM 2.0 on-board (Infineon SLB9665-TCG)
    Internal cards / # of slots/Type:Three M.2 slots
    -1st: WLAN M.2 2230 Card with PCIe x2 and USB
    -2nd for SSD M.2 2280 Card with SATA / PCIe x2/x4
    -3rd for SSD M.2 2280 Card with SATA / PCie x2/x4
    I/O Ports:1 x USB 3.1 Gen2 / Thunderbolt3 combo port (Type-C)
    4 x USB 3.0 (1x USB powered)
    2 x miniDP 1.3
    1 x HDMI 2.0 output
    1 x 2-in-1 Audio jack (Headdphone / S/PDIF optical output)
    1 x Microphone-in
    1 x Lineout
    1 x Line-in
    1 x RJ-45 LAN
    1 x DC-in
    Internal Keyboard:Backlit 7-colour full size keyboard with numeric pad
    TouchPad with multi-gesture and scrolling
    W/A/S/D Gaming key
    AC Adapter:330W 100-240V 50-60Hz Auto-switching (worldwide)
    optional 660W (2x 330W) for Extreme Performance
    Battery:8cells Smart Li-Ion; 89W
    FexiCharger (via BIOS)
    Weight:3.9kg / 8.58lbs
    Dimensions WxDxH:418x295x39.9mm / 16.72x11.81x1.6-inch
    Thickness:1.6in / 39.9mm
