| Launch Date: | November 15, 2017 |
| Special Feature(s): | Coffee Lake (Z370); 6cores/12treads CPUs; VR Ready; dual / SLI desktop GPUs; 120Hz LCD panel |
| Main Chipset: | Intel Z370 (Coffee Lake) |
| Processor: | Socket LGA 1151
Coffee Lake; up to i9-9900K; 8cores/16treads
|
| Video / GPU: | Two MXM 3.0 GPU slots; up to 190W
supports single or dual/SLI NVIDIA GeForce GTX 1080 (8GB GDDR5X), GTX 1070 (8GB GDDR5)desktop GPUs
|
| Built-in PC Camera: | Built-in 2M FHD |
| LCD Size: | 17.3in / 43.9cm |
| LCD Specifications: | 17.3" FHD, QHD, UHD; 60Hz/120hz/144Hz
Supports 4 active displays @ 4K/60Hz
Optional G-Sync |
| Memory: | Four 260-pin, 1.2V, SODIMM sockets
DDR4-2400/2666/3000; up to 128GB |
| Total Storage: | up to 5 physical drives:
- 3x M.2 2280 SSD PCIe Gen3 2x/4x or SATA
- 2x 2.5" 9.5mm/7mm HDD/SSD/SHDD
- RAID 0/1/5
- Supports Intel Optane Technology |
| Optical Drive: | External USB based
DVD-RW or Blu Ray Burner
|
| Card Reader: | 6-in-1 Push-Push Card Reader
MMC/RSMMC SD/mini SD/SDHC/SDXC
UHS-II (SD 4.0) |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in array microphone
Built in two 2W speakers (Foster) and subwoofer
Sound Blaster X Pro-Gaming 360°
ESS Sabre HiFi Audio DAC (Headphone)
|
| LAN/WLAN/Bluetooth: | - WLAN / Bluetooth; M.2 2230
- Two 10/100/1000 Ethernet LAN on-board; Killer E2400
- Support Killer Double Shot-X3 Pro
|
| Security: | Kensington Lock
Fingerprint
TPM 2.0 on-board (Infineon SLB9665-TCG) |
| Internal cards / # of slots/Type: | Four M.2 slots
-1st: WLAN M.2 2230 Card with PCIe x2 and USB
-2nd for SSD M.2 (2280) SATA / PCIe x2/x4 (NVMe)
-3rd for SSD M.2 (2280) SATA / PCie x2/x4 (NVMe)
-4th for SSD M.2 (2280) SATA / PCie x2/x4 (NVMe)
|
| I/O Ports: | 2x USB 3.1 Gen2 / Thunderbolt3 combo port (Type-C)
5 x USB 3.0 (1x powered USB port, AC/DC)
2 x mini DisplayPort 1.3
1 x HDMI 2.0 output
1 x Headphone/SPDIF (ESS Sabre HiFi)
1 x Microphone-in
1 x Line-out
1 x Line in
2 x RJ-45 LAN
1 x DC-in |
| Internal Keyboard: | Backlit (7 colours) full size keyboard with numeric pad
TouchPad with multi-gesture and scrolling
W/A/S/D Gaming key |
| AC Adapter: | 330W 100-240V 50-60Hz Auto-switching (worldwide)
optional 780W AC Adapter for Extreme Performance |
| Battery: | 8cells Smart Li-Ion; 89W
FexiCharger (via BIOS) |
| Weight: | 5.5kg/ 12.1lbs |
| Dimensions WxDxH: | 428x308x47.2mm; 17.1x12.3x1.88-inch |
| Thickness: | 1.88in / 47.2mm |
