Launch Date: | May 10, 2017 |
Special Feature(s): | Mobile Workstation class of laptop with Xeon C236 Chipset |
Main Chipset: | Intel CM236 Chipset
|
Processor: | Intel Xeon E3-1505M v5 on-board
|
Video / GPU: | Modular; MXM 3.0b NVIDIA Quadro M1000M, M2000M, M3000M, M4000M, M5000M |
Built-in PC Camera: | Built-in 2M FHD |
LCD Specifications: | 17.3" FHD 1920x1080 @60Hz; IPS eDP up to 4 active internal and/or external displays; up to 3084x2160 @ 60Hz
|
Memory: | Four 260-pin SODIMM sockets DDR4-2133; up to 64GB ECC |
Total Storage: | up to 6 physical drives: - 2x M.2 2280 SSD PCIe 2x/4x (NVMe) - 2x M.2 2280 SSD SATA - 1x 2.5" 9.5mm/7mm HDD/SSD/SHDD - 1x 2.5" 9.5mm/7mm HDD/SSD/SHDD (via ODD Bay) - RAID 0/1 |
Optical Drive: | External; USB based
|
Card Reader: | 6-in-1 Push-Push Card Reader Realtek RTS5249-GR MMC/RSMMC SD/mini SD/SDHC/SDXC UHS-II |
Audio Architecture: | High Definition Audio; Realtek ALC8980GR S/PDIF Digital Output Built in microphone Built in two 2W speakers and subwoofer Sound Blaster X-FI MB5 External 7.1CH output (headphone, mic, line-in and S/PDIF) ANSP 3D Sound Technology (headphone output) |
LAN/WLAN/Bluetooth: | - 1Gb Ethernet LAN on-board; Killer/Rivet E2400 - WLAN / Bluetooth; M.2 2230 slot
|
Security: | Kensington Lock Intel PTT |
Internal cards / # of slots/Type: | Five M.2 slots -1st: WLAN M.2 2230 Card with PCIe x2 and USB -2nd for SSD M.2 2280; SATA / PCIe x2/x4 -3rd for SSD M.2 2280; SATA / PCie x2/x4 -4th for SSD M.2 2280; SATA -5th for SSD M.2 2280; SATA
|
I/O Ports: | 1 x USB 3.1 (Thunderbolt 3 or DP 1.2 or HDMI 2.0) 6 x USB 3.0 1 x Mini Display Port 1.2 1 x HDMI 1.4b 1 x Headphone out / SPDIF 1 x Microphone-in 1 x Line in 1 x Line out 1 x RJ-45 LAN 1 x DC-in |
Internal Keyboard: | Multi-colour 7-colours backlit keyboard TouchPad with multi-gesture and scrolling W/A/S/D Gaming key |
AC Adapter: | 230W 100-240V 50-60Hz Auto-switching
|
Battery: | 8cells Smart Li-Ion; 7500mAh; 83.25Wh
|
Weight: | 3.85kg/ 8.47 lbs w/ battery |
Dimensions WxDxH: | 428x294x48mm / 17.12x11.76x1.92-inch |
