| Launch Date: | Nov 30, 2015 |
| Special Feature(s): | Built in Optical Drive
Discrete GPU on-board (GTX 960M) |
| Main Chipset: | Mobile Intel® HM170 Express Chipset |
| Processor: | Intel Mobile i7-6700HQ with HD 530 Graphics |
| Video / GPU: | NVDIA GeForce GTX 960M (2GB DDR5); on-board
Microsoft Hybrid Graphics
GPU switchable between iGPU and dGPU
|
| Built-in PC Camera: | Built-in 2M FHD Webcam |
| LCD Specifications: | 17.3" IPS FHD 1920x1080 @60Hz; eDP
Supports up to 4 active displays |
| Memory: | Two 204-pin SODIMM sockets
DDR3L-1600, 1866, 2133; 1.35V
up to 32GB |
| Total Storage: | up to 3 physical drives:
- 1st HDD/SSD SATA3 6Gb/s (9.5mm)
- 2nd M.2 2280 PCIe 2x/4x or SATA3 SSD
- 3rd HDD/SSD via ODD bay (9.5mm)
- Intel Rapid Start Technology
- Intel Smart Response Technology |
| Optical Drive: | - internal DVD or Blu Ray Burner; swappable with HDD/SSD
- Ultra Slim 9.5mm
|
| Card Reader: | 6-in-1 Push-Push Card Reader
MMC/RSMMC
SD/mini SD/SDHC/SDXC |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in microphone
Built in two 2W speakers
Sound Blaster Cinema 2
ANSP 3D Sound Technology (headphone output) |
| LAN/WLAN/Bluetooth: | M.2 2230 slot for WLAN/Bluetooth
|
| Security: | Kensington Lock
Fingerprint
TPM 2.0 on-board (Infineon SLB9665 TCG) |
| Internal cards / # of slots/Type: | Two M.2 card slots
-1st for WLAN M.2 2230
-2nd for SSD M.2 2280 SATA/PCIe x2/x4 |
| I/O Ports: | 4 x USB 3.0
1 x mini Display Port 1.2
1 x HDMI output
1 x VGA
1 x Headphone
1 x Microphone-in
1 x S/PDIF (digital)
1 x RJ-45 LAN
1 x DC-in |
| Internal Keyboard: | Backlit (white) full size with numeric pad
TouchPad with multi-gesture and scrolling; 108x63mm |
| AC Adapter: | 120W 100-240V 50-60Hz Auto-switching (worldwide)
DC Output 19.5V, 6.15A |
| Battery: | 6-cells Smart Li-Ion; 62WH
up to 280 minutes in UMA mode |
| Weight: | 2.9kg w/ battery |
| Dimensions WxDxH: | 413x285x31.9mm |
