| Launch Date: | January 10, 2015 |
| Special Feature(s): | Intel Z97 Express Chipset
Socket LGA 1150 Processors
HDMI 2.0
TPM 2.0
|
| Main Chipset: | Intel Z97 Express Chipset
|
| Processor: | Socket LGA 1150
TDP up to 90W
Intel Xeon E3 12xx v3
|
| Video / GPU: | MXM 3.0b; modular
NVDIA GeForce GTX 980M, GTX 970M and GTX 965M
NVIDIA Quadro K1100M, K3100M or K5100M
|
| Built-in PC Camera: | Built-in 2M FHD |
| LCD Size: | 17.3in (43.9cm) |
| LCD Specifications: | 17.3" FHD 1920x1080 @60Hz; LVDS/eDP
up to 4 active internal and/or external displays; up to 3084x2160 @ 60Hz
|
| Memory: | Four 204-pin SODIMM sockets
DDR3L-1600 or 1866; 1.35V
up to 32GB |
| Total Storage: | up to 4 physical drives:
- 1x M.2 2280 PCIe 2x/4x or SATA SSD or SATA3 SSD
- 1x M.2 2280 PCIe 2x or SATA SSD or SATA3 SSD
- 2x HDD/SSD SATA3 6Gb/s (9.5mm)
- Intel Rapid Start Technology
- Intel Smart Response Technology
- RAID 0/1 |
| Optical Drive: | External USB based
DVD-RW or Blu Ray Burner
|
| Card Reader: | 6-in-1 Push-Push Card Reader
MMC/RSMMC
SD/mini SD/SDHC/SDXC
UHS-II interface |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in array microphone
Built in two 2W speakers
Sound Blaster X-FI MB3
External 7.1CH output (headphone, mic, line-in and S/PDIF)
ANSP 3D Sound Technology (headphone output) |
| LAN/WLAN/Bluetooth: | - WLAN / Bluetooth; M.2 2230 slot
- 10/100/1000 Ethernet LAN on-board; Realtek RT8111G
|
| Security: | Kensington Lock
Fingerprint
TPM 2.0 on-board (Infineon SLB9665-TCG) |
| Internal cards / # of slots/Type: | Three M.2 card slots
-1st for WLAN Combo M.2 2230 Card with PCIe x2 and USB interface (A Key)
-2nd for SSD M.2 2280 Card with SATA / PCIe x2/x4 interface (M Key)
-3rd for SSD M.2 2280 Card with SATA / PCie x2/x4 interface (M key)
|
| I/O Ports: | 4 x USB 3.0 (1x powered USB port, AC/DC)
1 x eSATA/USB3.0 Combo port
2 x Display Port 1.2 (up to 3840x2160 @60Hz)
1 x HDMI 2.0 output (up to 3084x2160 @60Hz)
1 x Headphone
1 x Microphone-in
1 x S/PDIF (digital)
1 x Line in
1 x RJ-45 LAN
1 x DC-in |
| Internal Keyboard: | Backlit full size keyboard with numeric pad
TouchPad with multi-gesture and scrolling
W/A/S/D Gaming key |
| AC Adapter: | 230W 100-240V 50-60Hz Auto-switching (worldwide)
DC Output 19.5V, 11.8A
330W AC Adapter optional |
| Battery: | 8cells Smart Li-Ion; 82WH
up to 130 minutes |
| Weight: | 3.9kg (8.58lbs) |
| Dimensions WxDxH: | 418x282x16-38.7mm; 16.72x11.28x0.64-1.55-inch
|
| Thickness: | 16-38.7mm (0.64-1.55in) |
| Shipping / Packaging L xWx H / N.W. / G.W.: | 570x146x380mm / 22.8x5.84x15.2 inch
5.55kg / 12.2lbs |
