17.3-inch IPS FHD1920-by-1080 with Glossy (Glare) or Matte (Non-Glare); eDP

1/ World's first Intel Z170 based high performance laptop powered by Skylake-S socket processors, DDR4 memory and upgradeable MXM 3.0 graphics (Quadro and GeForce)
2/ Super fast 1Gigabit Killer E2400 LAN onboard
3/ Supports total 4 displays at 60Hz each (2x DP + 1x HDMI + 1x internal LCD)
4/ HDMI 2.0, USB 3.1 type C (Thunderbolt 3.0/DP 1.2/HDMI 2.0) and DP 1.2 ports
5/ USB powered port for charging external devices without powering system on
6/ Total four storage drives: 2x PCIe x4 M.2 slots + 2x 2.5" SATA3
7/ up to 64GB DDR4 SODIMM (four sockets)
8/ on-board TPM 2.0 for maximum security
9/ upgradeable VGA based on MXM 3.0b spec; including gaming GeForce and workstation Quadro
10/ full overclocking support for maximum performance with "K" series of Intel 6xxxK processors
11/ designed like a racing car with easy access to all components for future expansion / upgrades
12/ Anti Ghosting backlit keyboard with easy to change colors and glow effects of your illuminated keys.
13/ High capacity SD UHS II card reader
14/ Dual high fidelity microphones with noise cancellation on the laptop lid for stereo studio quality recording.
15/ Onkyo speakers with an enlarged speaker chamber for audio clarity.
16/ 7 high quality copper heat pipes covering the CPU and VGA array for shared thermal budget
CustomizeSpecificationsImagesBenchmarksReviewsPrice ListComponentsUser ManualDriversUpgradeUpgrade Price List
Launch Date:September 30, 2015
Main Chipset:Intel Z170 Express Chipset
Processor:Socket LGA 1151
TDP up to 90W
Skylake-S; up to i7-6700K
Video / GPU:1x MXM 3.0b slot
NVDIA GeForce GTX 980M, GTX 970M and GTX 965M
NVIDIA Quadro M1000M, M3000M, K3100M, M4000M, M5000M or K5100M
Built-in PC Camera:Built-in 2M FHD
LCD Specifications:17.3" FHD 1920x1080 @60Hz; LVDS or eDP
up to 4 active internal and/or external displays; up to 3084x2160 @ 60Hz
Memory:Four 260-pin; 1.2V; SODIMM sockets
DDR4-2133; up to 64GB
Total Storage:up to 4 physical drives:
- 2x M.2 2280 SSD PCIe 2x/4x or SATA
- 2x 2.5" 9.5mm/7mm HDD/SSD/SHDD
- RAID 0/1
Optical Drive:External USB based
DVD-RW or Blu Ray Burner
Card Reader:6-in-1 Push-Push Card Reader
Audio Architecture:High Definition Audio; Realtek ALC892
S/PDIF Digital Output
Built in microphone
Built in two 2W speakers and subwoofer
Sound Blaster X-FI MB5
External 7.1CH output (headphone, mic, line-in and S/PDIF)
ANSP 3D Sound Technology (headphone output)
LAN/WLAN/Bluetooth:- WLAN / Bluetooth; M.2 2230 slot
- 10/100/1000 Ethernet LAN on-board; Killer E2400
Security:Kensington Lock
TPM 2.0 on-board (Infineon SLB9665-TCG)
Internal cards / # of slots/Type:Three M.2 slots
-1st: WLAN M.2 2230 Card with PCIe x2 and USB (A Key)
-2nd for SSD M.2 2280 Card with SATA / PCIe x2/x4 (M key)
-3rd for SSD M.2 2280 Card with SATA / PCie x2/x4 (M key)
I/O Ports:1 x USB 3.1
3 x USB 3.0 (1x powered USB port, AC/DC)
1 x eSATA/USB 3.0
2 x Display Port 1.2
1 x Thunderbolt 3 (Alpine Ridge) via DP
1 x HDMI 2.0 output
1 x Headphone
1 x Microphone-in
1 x S/PDIF (digital)
1 x Line in
1 x RJ-45 LAN
1 x DC-in
Internal Keyboard:Backlit full size keyboard with numeric pad
TouchPad with multi-gesture and scrolling
W/A/S/D Gaming key
AC Adapter:230W 100-240V 50-60Hz Auto-switching (worldwide)
DC Output 19.5V, 11.8A
330W AC Adapter optional
Battery:8cells Smart Li-Ion; 82WH
up to 130 minutes
Weight:3.9kg/ 8.58 lbs w/ battery
Dimensions WxDxH:418x282x16-38.7mm; 16.72x11.28x0.64-1.55-inch
Shipping / Packaging L xWx H / N.W. / G.W.:570x146x380mm / 22.8x5.84x15.2 inch
5.55kg / 12.2lbs
